Cervical Spine Posterior to Anterior Mobilization

Cervical Spine Posterior to Anterior Mobilization is a technique used to help reduce neck pain, stiffness, and tension. It is a type of manual therapy which involves the clinician to place their hands below the patient’s neck and use controlled pressure to move the patient’s cervical vertebrae in a posterior to anterior (back to front) direction. This technique can be used to relieve muscle tightness and improve range of motion as well as helping to alleviate

Transcript

00:00:0200:00:07
This is Brent of the Brookbush Institute, and in this video we're going to go over a
00:00:0200:00:07
...blank
00:00:0700:00:11
joint based manual therapy technique. If you're watching this video I'm assuming
00:00:1100:00:14
you're watching it for educational purposes, and that you are a licensed
00:00:1400:00:19
professional with joint based techniques within your scope. That means osteopaths,
00:00:1900:00:23
chiropractors, physical therapists you're probably all in the clear. Physical
00:00:2300:00:27
therapy assistants, athletic trainers, massage therapist you need to check
00:00:2700:00:30
with your governing body in your state or region, to see whether this is within
00:00:3000:00:35
your scope of practice. Personal trainers this is definitely not within your scope
00:00:3500:00:39
of practice. Of course all professions could use this video for purely
00:00:3900:00:45
educational purposes to help with learning biomechanics, anatomy and of
00:00:4500:00:48
course palpation. In this video we're going to go over posterior to anterior
00:00:4800:00:52
mobilizations for the cervical spine. Now that's unilateral posterior to anterior
00:00:5200:00:56
mobilizations, which i think you guys will find is the workhorse of all of the
00:00:5600:01:00
mobilization techniques we use for the entire spine. I'm going to have my friend
00:01:0000:01:03
Melissa come out, she's gonna help me demonstrate these techniques. The first
00:01:0300:01:05
thing I'm going to talk about is set up a little bit. We're going to have Melissa
00:01:0500:01:11
face down in the face cut out here, and just so that we save her more
00:01:1100:01:15
sensitive cheek bones, remember we're going to be pressing down on her neck, which
00:01:1500:01:19
means we're going to be pressing her down into the table a little bit. I'm going to go
00:01:1900:01:23
ahead and have her use a towel so that her forehead takes most of the force.
00:01:2300:01:27
We're not going to be pressing that hard, but this area tends to get easily
00:01:2700:01:31
aggravated, especially if we have multiple segments or multiple facet
00:01:3100:01:34
joints we have to mobilize. Now the next thing is we want the arms in a
00:01:3400:01:39
comfortable relaxed position, that could be by their sides, that could be hanging
00:01:3900:01:43
off the table. Or if you're lucky enough to be here at Flex in New York where I
00:01:4300:01:48
treat, like we have the arm cutouts that depress. So you can see Melissa can just
00:01:4800:01:51
kind of hang out in this position, which tends to be very comfortable for
00:01:5100:01:55
cervical patients. The thing you're trying to avoid is we don't want
00:01:5500:01:59
increased tension here, right the muscles that go from the scapula to the cervical
00:01:5900:02:04
spine, namely her levator scapulae and upper trap. Lastly you will notice
00:02:0400:02:09
that the table is pretty low, and the reason the table is low is I want to be
00:02:0900:02:16
able to get my chest over Melissa's neck, and then put my arms straight and have
00:02:1600:02:21
my thumbs right where they need to be; because once we start doing the mobilization all
00:02:2100:02:26
I want to have to do is rock my torso. I don't want to be in a position where I
00:02:2600:02:33
have to either use my hands or my elbows, right like extension using my triceps
00:02:3300:02:37
because number one if I have a lot of very large patients I'm going to wear
00:02:3700:02:41
myself out really quick, and even if I don't have a lot of large patients I
00:02:4100:02:44
think you guys will find that this is just not a consistent amount of force.
00:02:4400:02:48
It's hard to be really really consistent when you're doing this. Or you're doing
00:02:4800:02:55
this compared to okay I get here, and now I just rock. It's really easy to keep a
00:02:5500:03:02
very consistent amount of force this way. Next thing we need to consider is
00:03:0200:03:07
anatomy, and if you haven't spent some time going over cervical spine
00:03:0700:03:10
anatomy I suggest doing a little review before you start practicing these
00:03:1000:03:16
techniques. And I do suggest you purchase or find one of these to practice on. I
00:03:1600:03:20
know they're a little expensive for what they are. I think they run between 80 and
00:03:2000:03:25
150 bucks right. I bought one of the flexible ones, and let me explain why. I
00:03:2500:03:32
know this and this aren't exactly the same, but this is a close facsimile to
00:03:3200:03:37
the bones and joints of the cervical spine, and there's something to being
00:03:3700:03:45
able to touch, feel all the different bumps. Challenge yourself to go okay I'm
00:03:4500:03:49
going to find the transverse process of C1. All right and then be able to look down
00:03:4900:03:56
and go oh I'm on the transverse process of C1. Or I go I'm going find spinous
00:03:5600:04:05
process of C3. All right I did it, I did it, I remembered that C1 doesn't really
00:04:0500:04:11
have a spinous process. So as I'm doing this what I'm doing is building a
00:04:1100:04:16
visual model up here of what the bones of the neck look like, and I can't tell
00:04:1600:04:22
you how helpful that is when you get your hands here, which is basically that
00:04:2200:04:27
with a bunch of mush on top of it. It's not exactly the same. I'm not saying it's
00:04:2700:04:32
exactly the same, but I think it's going to help you guys as a learning tool
00:04:3200:04:36
that once you get your hands in here and you can get through the soft tissue, you
00:04:3600:04:38
get better at feeling through the soft tissue,
00:04:3800:04:43
you'll start being able to match up your visual model with what's actually going
00:04:4300:04:47
on here a lot quicker. Now we are going to start with the most complicated
00:04:4700:04:51
joints of the neck to actually palpate and mobilize, but that's just because
00:04:5100:04:55
we're going start from the top and work our way down. So let me show you guys how
00:04:5500:05:02
to palpate C1, and then how we're going to mobilize C1-CO, or the atlanto-
00:05:0200:05:10
occipital joint. So if you guys feel the back of the skull and then take the back
00:05:1000:05:14
of the skull towards the ears, and find that little point known as the mastoid
00:05:1400:05:16
process right that's like right here,
00:05:1600:05:19
and some of you have felt your mastoid processes before, they can be a
00:05:1900:05:23
little tender to poke on. And you guys go what does that have to do with the
00:05:2300:05:27
cervical spine? Well if you go just inferior to your mastoid process, you can
00:05:2700:05:32
actually feel it on yourself, you run into like two hard things sticking
00:05:3200:05:38
out this way. That's actually the transverse process of C1 all right. So
00:05:3800:05:41
find that on your patient and then look down, and I want you to draw an imaginary
00:05:4100:05:46
line between your two fingers. The little horizontal line between your two
00:05:4600:05:51
fingers and think C1's right under that. Alright so I know C1 is right under
00:05:5100:05:57
that line, and then if you can remember that the atlanto-occipital joint tilts
00:05:5700:06:04
towards the person's eyes. You can think okay if that's C1 I need to go just
00:06:0400:06:10
above C1 so that I can get on that AO joint, and I need to push in this
00:06:1000:06:16
direction. So what I'm going to have you guys do is trade your index fingers
00:06:1600:06:18
which you were probably palpating the transverse process with, with your
00:06:1800:06:25
pinkies. Lay your fingers over right where you think C1 is, and then think
00:06:2500:06:30
okay which side am I going to do. I want you to put your thumbs where these two
00:06:3000:06:36
fingers were. So if I had just laid down my fingers like this over C1, I'm now
00:06:3600:06:40
going to put my thumbs right over where my middle and fourth finger were on one
00:06:4000:06:45
side, and then I'm going to try to push up towards the eyeball. And I think you guys
00:06:4500:06:49
will find that as you gently push in and kind of
00:06:4900:06:53
give a couple test presses, you'll feel that joint move a little bit.
00:06:5300:06:59
Now I actually find this position a little uncomfortable for me so I tend to
00:06:5900:07:04
put my thumb down on this side if I'm going to mobilize this joint, and then I use
00:07:0400:07:09
this arm over that thumb. Once again I have kind of big hands right, so for me
00:07:0900:07:14
to do thumb thumb next to thumb is really tough, and then I'm just going to
00:07:1400:07:23
mobilize in the direction of her eye here just like so. All right so that's
00:07:2300:07:32
how I find that that occipital and Atlas joint, right that AO joint or CO-C1 joint.
00:07:3200:07:37
Now notice guys I went thumb over thumb. All of the techniques for the cervical
00:07:3700:07:41
spine are either thumb next to thumb or thumb over thumb, and be careful don't
00:07:4100:07:46
let yourself get into extension too much in your thumbs like that can ruin
00:07:4600:07:49
careers if you keep doing it. You end up with hypermobility there and then it
00:07:4900:07:53
becomes really hard to do these techniques, and try to use both hands
00:07:5300:07:58
whenever possible so that you gain the benefit of the strength of both your
00:07:5800:08:01
thumbs, rather than wearing down one. Like I'm sure I could get in here and I have
00:08:0100:08:05
enough hand strength to do it just like this, but that's going to wear me down over
00:08:0500:08:15
time. This is a much safer technique for my hands. So we have CO-C1 let's go C2-C3.
00:08:1500:08:23
If I look for the spinous process that's just underneath Melissa's skull, that
00:08:2300:08:29
spinous process is C2. So C1 doesn't have a spinous process. If I then drop
00:08:2900:08:42
slightly lateral and inferior, I end up on the facet joint of C2-C3. Now you'd
00:08:4200:08:49
think well that's easy enough and then I can just press down, and I know some of
00:08:4900:08:53
you guys have already figured out that I skipped C1-C2, and there's this little
00:08:5300:08:59
trick. So if I find the spinous process and drop off that's C2-C3
00:08:5900:09:05
and I can do my normal PA if C2-C3 and I can either do it this way getting over
00:09:0500:09:11
the top, or I can do it this way getting over the top, and again I'm thumb over
00:09:1100:09:14
thumb because my thumb's are fairly large. If you feel more comfortable this
00:09:1400:09:19
way that's fine. I'm going to find my first resistance barrier and then push through
00:09:1900:09:24
to the end. Find the end point, you guys are going to find that there's not a lot of
00:09:2400:09:28
range of motion there. I back off to 50%, then I can do either my grade 3's or
00:09:2800:09:35
my grade 4's. For C1-2 you got to remember what joint that is, so
00:09:3500:09:42
that's the atlanto-axial joint, the the AA joint. That joint wants to rotate
00:09:4200:09:48
and if you just press down on C1-C2 like I'm pressing down on C2 here,
00:09:4800:09:54
there's too much left because of rotation for that mobilization to be
00:09:5400:10:00
effective. So what we need to do is get to end range of motion and then start
00:10:0000:10:03
mobilizing, and the way we do that is just turn
00:10:0300:10:06
Melissa's head about 30 degrees. So she's just going to lay on one side like
00:10:0600:10:11
she'd lay on a pillow, and I'm going to go back to that same facet, that same
00:10:1100:10:17
bump; because I was basically over the top of C2. So just right here and
00:10:1700:10:25
then I'm going to push straight down, and then of course retest rotation.
00:10:2500:10:31
So quick recap here, and once again these are the hardest joints and the
00:10:3100:10:37
cervical spine to figure out. So if you can get these you're in good shape. For
00:10:3700:10:46
C1 and the occiput you're going to go towards her eyeball just
00:10:4600:10:52
underneath the occiput. So you can go over the top this way or you can
00:10:5200:10:56
come around to the side, and then I end up using this arm, because this arms now
00:10:5600:11:02
facing eyeball, this is my dummy thumb and I can go this way. If I then find the
00:11:0200:11:06
spinous process of C2 and drop off laterally, you end up naturally wanting
00:11:0600:11:12
to drop off laterally and inferiorly a little bit, that bump was over the top of
00:11:1200:11:18
the articular pillar of C2. If I press straight down that's actually mobilizing
00:11:1800:11:23
C2-C3 which is fine if that's what you want to mobilize. If you were looking for
00:11:2300:11:29
upper cervical rotation though and you think that C1-C2 is stuck, then you're
00:11:2900:11:35
going to need to rotate towards and press down because I needed to take up that
00:11:3500:11:42
end range rotation, like basically turn C1 all the way like this and then press
00:11:4200:11:48
down on C2 to get more range. Guys that was the hard part, that was the hard part.
00:11:4800:11:53
If you got that rewind this video watch that a couple times. If you got that the
00:11:5300:11:59
rest is easy breezy. So C3 now we're starting to get into mid
00:11:5900:12:05
cervical spine, fall-off just lateral and inferior. I like to come around this
00:12:0500:12:13
side, it's just straight down, and then c4 is just one segment down again, C5 one
00:12:1300:12:19
segment down again, C6 one segment down again. Now you guys know C7 and spinous
00:12:1900:12:27
prominence, so that's that's right here for her, right and then I can go right there. So I can
00:12:2700:12:31
mobilize all of those joints, there's nothing special about them. It's just, you
00:12:3100:12:36
just kind of go lateral and you end up dropping off just a little tiny bit, and
00:12:3600:12:42
I can go straight through all of these. Now let's talk a little bit about
00:12:4200:12:45
what I'm feeling for as I'm doing these mobilizations. I already mentioned it a
00:12:4500:12:51
little bit, don't forget your protocols. So every time I get over the top of the
00:12:5100:12:58
joint before I mobilize I'm going okay, there's my first resistance barrier,
00:12:5800:13:03
there's the end of articular arthrokinematic motion, before I would just
00:13:0300:13:07
start pushing her into a further extension. So my end range of
00:13:0700:13:14
this motion, so first resistance barrier and usually if I'm going to do
00:13:1400:13:19
this I'm not going to go argh end. I'm going to kind of do some
00:13:1900:13:23
test pulses my way down until I get to the end, see if the patient depending on
00:13:2300:13:27
how sensitive they are can take it. I'm going to back off the 50%
00:13:2700:13:33
and now I have my choice, I can either do larger amplitude grade 3's
00:13:3300:13:38
going from first resistance barrier down to 50%, or maybe just a little beyond 50%.
00:13:3800:13:41
Or I can do my grade fours which are a little bit more intense, because I'm
00:13:4100:13:47
going to start at 50% and do small amplitude, or go even deeper as I need to.
00:13:4700:13:55
So get here 1-2 oscillations per second, and I'm going to keep going
00:13:5500:14:03
probably for 30 seconds or more until I feel a change in tissue sensitivity.
00:14:0300:14:09
Or not tissue sensitivity I guess is the wrong word, maybe malleability tissue
00:14:0900:14:18
density. I'll feel like it's easier to move the joint. How does that feel
00:14:1800:14:25
Melissa? Feels good. Now we do have to be very careful. With the cervical spine we
00:14:2500:14:30
are as likely to end up with a hyper mobile segment as we are to end up with
00:14:3000:14:34
a hypomobile segment, and I think we get into the unfortunate habit of going
00:14:3400:14:41
diagnosis modality, right that's how we treat right. Cervical pain,
00:14:4100:14:45
mobilizations is what fixes it, and we have to keep in mind that that's not
00:14:4500:14:51
very good logic. Mobilizations are to increase mobility, and if somebody has
00:14:5100:14:57
pain because they're hypermobile then we could be making the problem worse.
00:14:5700:15:01
And the unfortunate thing is a hypermobile person sometimes feels very tight,
00:15:0100:15:06
because they end up with a lot of spasming an increase in tonicity in
00:15:0600:15:10
those extensor muscles. So it is very important that as you're doing these
00:15:1000:15:13
mobilizations, unless you've been with this patient for a long time and try
00:15:1300:15:21
this before, I would do one facet joint have him sit up and redo my tests.
00:15:2100:15:25
See if that reduced their pain, increase their range of motion. If it increased
00:15:2500:15:28
their pain, I'm heading in the wrong direction.
00:15:2800:15:33
It could mean that I chose the wrong facet, but I mobilized the hypermobile
00:15:3300:15:36
facet rather than a hypomobile facet. It could also mean that
00:15:3600:15:40
mobilizations maybe aren't the most appropriate thing to start with, and
00:15:4000:15:43
maybe we should back off and start thinking about maybe this person needs
00:15:4300:15:48
more of like exercise first, stability exercises first. Or maybe I need to leave
00:15:4800:15:53
the neck alone and maybe treat out the upper thoracic spine, and I see
00:15:5300:15:58
if I can get some good progress that way, let their neck calm down before
00:15:5800:16:03
I come back to these more aggressive techniques that directly affect where
00:16:0300:16:11
they're having pain. All right so just to review here real quick, CO,
00:16:1100:16:16
C2-C3 is just off that first
00:16:1600:16:24
spinous process you feel. If I rotate 30 degrees C1-C2, all of the other cervical
00:16:2400:16:30
facets feel like little bumps, you're getting it right over what the, it's
00:16:3000:16:34
called the articular pillar and when you look at the spine the cervical spine all
00:16:3400:16:37
they're talking about with the articular pillar is the facet joints
00:16:3700:16:41
stack up in such a way that they feel like pillars on either side of the
00:16:4100:16:46
spinous process. So for the rest of the cervical spine joints you're just
00:16:4600:16:51
getting right lateral and slightly inferior and pressing down, and we're
00:16:5100:16:59
probably mobilizing the upper on the lower segment, and you guys can just
00:16:5900:17:05
think about that as you go through and feel each one of these bumps right
00:17:0500:17:13
that's that's connected to the spinous process. As you try to loosen up all of
00:17:1300:17:18
those cervical facets. Stay tuned for your close-up recap. Now for the
00:17:1800:17:23
close-up recap all of the palpations and the various ways to do these UPA
00:17:2300:17:27
mobilizations for the cervical spine which is a little complicated, we're
00:17:2700:17:31
going to go ahead and start from the top and work our way down again.
00:17:3100:17:35
You're going to find the mastoid process which is this little bump I think you
00:17:3500:17:39
can see sticking out right here, right behind Melissa's earlobe, and then
00:17:3900:17:46
if you go just below that on either side of her spine, you'll feel these two
00:17:4600:17:50
things sticking out like so, and those are her transverse process;
00:17:5000:17:56
and then if I put my pinkies on those transverse process and just lay my
00:17:5600:18:01
fingers down horizontally just underneath her occiput, my fingers are
00:18:0100:18:10
right over C1. Now if I want to do this side over here and I just replace my
00:18:1000:18:17
third and fourth finger with my thumbs, I'll be over that CO-C1 joint, and
00:18:1700:18:23
then I can push down find my first resistance barrier. Remember that
00:18:2300:18:27
I'm pushing down towards her eyeball, so this one's not straight on, this isn't
00:18:2700:18:33
not a straight on PA this way, it's this way a little bit. So I have to kind of
00:18:3300:18:39
push back in towards her head and I'll find my first resistance barrier, my end
00:18:3900:18:46
range, back off to 50%, and then do either my grade 3's or my grade 4's. Now the
00:18:4600:18:54
next one we're going to find is actually C2-C3, and if I drop off laterally and
00:18:5400:18:59
inferiorly from C2 spinous process, remember the C2 spinous processes the
00:18:5900:19:04
first spinous process we feel underneath the occiput; because C1 essentially
00:19:0400:19:10
doesn't have a spinous process. So if I go right over C2-C3 I can go ahead and
00:19:1000:19:17
do my normal straight up and down PA over that little bump I feel, essentially
00:19:1700:19:24
between C2 and cC3 spinous processes just lateral to it, and so that bump.
00:19:2400:19:29
Where is my first resistance barrier, where's my end, back off to half. Now just
00:19:2900:19:35
like in the video you guys will notice I went CO-C1, C2-C3 because to get to C1-C2
00:19:3500:19:41
I need to turn Melissa towards me or towards the side that I'm mobilizing,
00:19:4100:19:48
because I need to take up all that slack in the atlanto-axial joint which wants
00:19:4800:19:51
to rotate. So if we're going to improve range of motion we need to get pretty
00:19:5100:19:56
close to end range, but then once they get her in this position I'm just going to
00:19:5600:20:03
go back to C2 spinous process, fall off and do a PA, same thing.
00:20:0300:20:07
So it's not a more complicated technique you just have to remember the
00:20:0700:20:14
little trick of taking up all of the upper cervical rotation you can, and then
00:20:1400:20:19
for the rest of the spinous process it's just fall off, a little lateral, a little
00:20:1900:20:26
medial unto what feels like an articulatar pillar, a column, our
00:20:2600:20:32
articular pillar, you can feel those little bumps. That little bump this
00:20:3200:20:36
way, and there's even a little bumpiness this way that each facet joint you just
00:20:3600:20:43
do your PA's, go to the next spinous process, do your PA, next one. As long as
00:20:4300:20:49
it feels stiff you can keep going, or you can do one and then retest. Or you
00:20:4900:20:52
could do one and then do the other side if you think it's more of like a
00:20:5200:20:58
bilateral restriction. These PA's will work all the way into the upper thoracic
00:20:5800:21:03
spine for sure, even coming over the top of somebody as I am here. You could be on
00:21:0300:21:08
the side of somebody if you think something is unilateral do all one side
00:21:0800:21:14
and then retest. So the rest of these segments are real easy, just fall off
00:21:1400:21:20
this way find your first resistance barrier, your end resistance barrier, back
00:21:2000:21:26
off to 50%. Of course zero to fifty for a grade three or stay closer to fifty be a
00:21:2600:21:33
little bit more intense, and this would be our grade four mobilizations. As per
00:21:3300:21:40
all our techniques assess, address and reassess. I hope this helped make sense
00:21:4000:21:45
of these palpations for you. So there you have it assess, address, reassess. Make
00:21:4500:21:49
sure that every time you choose a joint based manual therapy technique it is
00:21:4900:21:53
based on an assessment, and that you return to that assessment after you've
00:21:5300:21:58
finished the intervention to see if it was effective for the individual ,the
00:21:5800:22:02
patient or client that you have in front of you. Ensure that you continue to learn
00:22:0200:22:07
your Anatomy because your Anatomy is going to help you with your hand
00:22:0700:22:12
placement, with understanding what a joint can do, with understanding what you
00:22:1200:22:18
may gain from this particular technique, and of course practice. You have to
00:22:1800:22:23
practice these techniques hopefully not for the first time on a patient or
00:22:2300:22:27
client who just walked in the door. If you can find a more senior instructor or
00:22:2700:22:33
a mentor to give you some really good hands-on instruction, use your peers for
00:22:3300:22:41
some good feedback, and of course always look for live education to help with
00:22:4100:22:45
your manual therapy techniques. I know these videos make education very
00:22:4500:22:51
convenient, but there is no substitute for learning manual therapy in a live
