Cuboid Manipulation

This video demonstrates cuboid manipulation, a technique intended to reduce excessive stiffness of the tarsal joints. The term "manipulation" refers to a low-amplitude (relatively small motions), high-velocity (quick) technique, with the intent to target specific joints or segments, that exhibit a decrease in passive accessory range of motion (a.k.a. stiffness during arthrokinematic motion; specifically glide). Cuboid manipulation may be used to address dorsiflexion range of motion, less than optimal longitudinal arch height, and/or abnormal lower extremity muscle activity. For example, research demonstrates that pes planus is correlated with Achilles tendinopathy, and manipulation of the transverse tarsal joints may aid in normalizing activity of the tibialis posterior, tibialis anterior, and peroneal muscles during gait. This technique is recommended for all clinical human movement professionals (physical therapists, physical therapy assistants, chiropractors, occupational therapists, etc.) to aid in development of an evidence-based, systematic, integrated, patient-centered, patient-centered, and outcome-driven approach.

Transcript

00:00:0400:00:07
This is Brent of the Brookbush Institute,
00:00:0400:00:07
in this video we're going to go over
00:00:0700:00:11
manipulations or high-velocity thrust techniques. I assume that if you're
00:00:1100:00:14
watching this video you're watching it for educational purposes, and that you
00:00:1400:00:19
are a licensed professional with high- velocity thrust or manipulation
00:00:1900:00:24
techniques in your scope of practice. If you are not sure check with your state
00:00:2400:00:28
board. Most physical therapists, chiropractors and osteopaths you're in
00:00:2800:00:33
the clear. I believe that ATC's you can't do manipulations in the United States,
00:00:3300:00:38
although other countries again check your scope. Of course massage therapists
00:00:3800:00:41
and personal trainers these are generally not within your scope. Of
00:00:4100:00:47
course you could continue to watch these videos just for educational purposes,
00:00:4700:00:51
learn a little Anatomy, learn a little biomechanics. If you're going to do these
00:00:5100:00:56
techniques please make sure that you have a good rationale for putting your
00:00:5600:01:00
hands on a patient, this should be based on assessment, and if you're going to
00:01:0000:01:06
assess I'm hoping that you'll assess, use these interventions and reassess to
00:01:0600:01:09
ensure that you're getting the result that you're looking for and have good
00:01:0900:01:13
reason to continue using this technique. In this video we're going to do a cuboid
00:01:1300:01:15
manipulation. I'm gonna have my friend Yvette come out, she's going to help me
00:01:1500:01:17
demonstrate. Remember if I'm doing manipulations, I'm using more than
00:01:1700:01:21
passive accessory motion and more than just subjective complaints. We want to
00:01:2100:01:26
make sure that we have some sort of movement or postural exam like the
00:01:2600:01:29
overhead squat assessment, to see what compensation pattern were actually
00:01:2900:01:33
trying to correct, and I like to use continuous interval measures to track
00:01:3300:01:37
progress, that's something we can measure objectively. In this case I'd probably
00:01:3700:01:41
use the navicular drop test with like a ruler, so I can see how many centimeters
00:01:4100:01:46
of height we have between the navicular tubercle and the floor. Now the
00:01:4600:01:50
last thing I'm going to go to is of course my passive accessory motion exams, to
00:01:5000:01:54
indicate whether this particular joint is stiff, and it's actually several
00:01:5400:01:58
joints here. We are manipulating the cuboid bone but we have to keep in mind
00:01:5800:02:04
that the cuboid has joints with the calcaneus, the lateral cuneiform and the
00:02:0400:02:11
navicular a little bit; and what we're trying to to do is see if it'll tilt
00:02:1100:02:16
this way on the combination of those three joints. Now the first thing
00:02:1600:02:20
we have to do is be able to palpate the cuboid which is not terribly hard. If
00:02:2000:02:23
you just think about the fact that the cuboid is on the lateral
00:02:2300:02:28
side of the foot, and essentially on the lateral side of the foot you can palpate
00:02:2800:02:36
the calcaneus, the fifth metatarsal or the cuboid. Now what I'll usually do just
00:02:3600:02:40
kind of instinctively, is I'll start grabbing at the side of the foot until I
00:02:4000:02:45
feel something that feels wedge-shaped. All right like right here
00:02:4500:02:53
it feels a little wedge-shaped, but it's not the round long bone of the fifth
00:02:5300:02:56
metatarsal. So I got this wedge-shaped bone in it, it'll actually
00:02:5600:03:00
wiggle for me. So this will wiggle, this is definitely skin there's no bone here.
00:03:0000:03:04
This is a bone that'll wiggle, and then this one you can
00:03:0400:03:09
feel the whole lever move. So now that you have the cuboid,
00:03:0900:03:13
really kind of take a second to palpate around. You'll notice it's a pretty
00:03:1300:03:17
sizable bone, it feels like almost half the width of the foot. So it
00:03:1700:03:22
takes, not this way right, it's only about, maybe on Yvette's little foot here
00:03:2200:03:28
maybe an inch and a half long, but it it's almost as wide as like half
00:03:2800:03:31
the foot there. So I'll feel around there,
00:03:3100:03:34
you kind of feel like, you get this feeling like it has like a little
00:03:3400:03:40
curvature to it, so like it's shaped a little like if I turned my hand
00:03:4000:03:46
this way, right so I can kind of put my thumb in this little divot and the
00:03:4600:03:50
cuboid, or at least it feels that way. So now what I want to check is
00:03:5000:03:54
this when I do my passive accessory motion. Of course I can just
00:03:5400:04:00
wiggle back and forth, dorsal to plantar. But what I think you are going to find
00:04:0000:04:08
is that's not what gets stuck. What gets stuck is the ability to move this way,
00:04:0800:04:15
almost like a rotation, and I guess we could call that external rotation of the
00:04:1500:04:20
of the cuboid bone, but it's probably more like inversion, e-version
00:04:2000:04:27
of the cuboid bone, and I think you'll get this sense that the medial edge
00:04:2700:04:32
doesn't want to move the same. So the outside edge will wiggle on you a
00:04:3200:04:35
little bit, and then you get to the medial edge and your like that does feel a little
00:04:3500:04:43
stuck. So now how do we manipulate this joint? So keep in mind manipulations are
00:04:4300:04:46
always about setup first, just because we know where this bone is we don't just
00:04:4600:04:50
want to go snap, it's not going to work. Remember we're trying to get range of
00:04:5000:04:54
motion back, so we want to lock out all the range of motion she has in a
00:04:5400:04:58
particular direction, and then push past the resistance barrier; and the way that
00:04:5800:05:02
looks with this this particular joint is I'm going to put the cuboid right here in
00:05:0200:05:11
my hand on the outside. I actually like to use my thumb on the inside, so
00:05:1100:05:14
I'm just like this and I'll show you this closer on the close-up recap,
00:05:1400:05:22
and what I'm going to try to do is twist the cuboid this way. But before I do that,
00:05:2200:05:28
I have to lock the cuboid out. So I'm going to take all of the inversion that I
00:05:2800:05:32
have up. All right I'm going to take her all the way as far into inversion as I
00:05:3200:05:38
possibly can. I'm going to plantar flex the foot as well, not plantar flex the ankle
00:05:3800:05:45
plantar flex here, her metatarsals, her transverse tarsal joint. I want to
00:05:4500:05:52
take up all the slack in the top of her foot. So I get here and then what you
00:05:5200:05:58
want to do is not this right, which is instinctively like plantar to dorsal
00:05:5800:06:02
you'd be like yeah that's the manipulation right. But with this particular
00:06:0200:06:05
manipulation there's so much leg involved that if I did this, you can
00:06:0500:06:10
see it's just got knee extension, that's not what I was trying to do. I want to
00:06:1000:06:16
get more inversion at the cuboid so I'm going to take up all the slack on the foot
00:06:1600:06:22
here and then this is cool. All you really need to do is just go like that,
00:06:2200:06:26
it's a whip. I don't know if you guys heard that, that was actually a pretty a
00:06:2600:06:29
pretty loud cavitation for the cuboid. Usually this is one of those ones that
00:06:2900:06:33
you'll feel the cavitation and you won't hear it, but I just took up all the slack
00:06:3300:06:42
and then I just whipped her foot. Wow. So again, find the cuboid,
00:06:4200:06:47
the outside of the cuboid on this part of your hand, so this is going to help
00:06:4700:06:52
us turn into inversion from the top side. This side you're going to press the medial
00:06:5200:06:58
portion of the bone down this way. I've even seen some people with really great
00:06:5800:07:04
technique here use their pisiform hamate like this. My problem is my hands are
00:07:0400:07:08
kind of stupidly big, and I can't get that part of my hand into that part of
00:07:0800:07:12
this little foot. I just happened to be a lot bigger than Yvette. For some
00:07:1200:07:16
of you with less difference between the size of your patient and
00:07:1600:07:19
yourself that might work out better, and then you can get to the end range here
00:07:1900:07:24
and that would look a little bit more like a PA. You would do a whip but it would be
00:07:2400:07:30
more like a PA you do on the spine. So that might be more comfortable for some
00:07:3000:07:36
of you, but again you're going to outside, wraps up the outside of the cuboid, here
00:07:3600:07:42
I'm going to end up using my thumb on the medial portion, plantar flex all the way.
00:07:4200:07:49
Not the ankle necessarily, the foot, invert as far as you can. Again,
00:07:4900:07:54
forefoot not necessarily the ankle. Get all the way to end range where you feel
00:07:5400:07:57
that lock position, and play with it if you have to for a second like really
00:07:5700:08:00
feel like you have the cuboid to a point that it doesn't want to move anymore, and
00:08:0000:08:03
then once you're there just give it a little whip.
00:08:0300:08:07
Alright stay tuned for the close-up recap. For a close-up recap you
00:08:0700:08:12
can see here like if you grab here you got the calcaneus then you got some
00:08:1200:08:16
skin, and then right as I get down to about here like I feel bone again, this
00:08:1600:08:22
is her fifth metatarsal, this is her cuboid. So I'm going to put my thumb on the
00:08:2200:08:28
medial aspect of her cuboid, then I'm going to take this part of my hand, put it
00:08:2800:08:34
on the outside of her cuboid, and my goal here is to push this way with this
00:08:3400:08:40
finger and then pull up this way with my hand, so that I'm tilting the cuboid this
00:08:4000:08:46
way. So we get all set up and then I mentioned before remember we want
00:08:4600:08:50
inversion and plantarflexion of the foot, and you can see the difference
00:08:5000:08:54
between inversion and plantar flexion of the ankle where you get all this
00:08:5400:08:59
calcaneal motion, as opposed to inversion and plantar
00:08:5900:09:04
flexion of the foot. You can see the calcaneus stays basically in place.
00:09:0400:09:11
So once I get her all locked up I can pull all the way down into end-
00:09:1100:09:16
range, and then of course this time the manipulation is not just like a thrust
00:09:1600:09:23
PA, we're just going to give the the foot a little whip, and that's it, that was the
00:09:2300:09:29
entire manipulation. So take your time getting set up, get your hand over the
00:09:2900:09:33
cuboid, get your thumb or you can use pisiform hamate in here if you got
00:09:3300:09:37
smaller hands, or at least hands that are smaller compared to the person's foot.
00:09:3700:09:42
You're gonna plantarflex and invert the forefoot as far as you possibly can,
00:09:4200:09:47
and then just a little whip, and of course you could use something like
00:09:4700:09:52
the navicular drop test to go ahead and measure pretest, post-test. A couple of
00:09:5200:09:56
points to recap, knowing your Anatomy and knowing your biomechanics will certainly
00:09:5600:10:00
help you choose the right technique for the right patient. If you're unsure
00:10:0000:10:06
whether manipulations are appropriate due to their higher intensity it's okay
00:10:0600:10:10
to do mobilizations. Most research points to manipulations being slightly more
00:10:1000:10:15
effective, but mobilizations being very effective, and of course we have those
00:10:1500:10:20
videos for you if you want to start with those less-intense techniques. Make sure
00:10:2000:10:24
that if you are doing any technique that is based on assessment, and of course
00:10:2400:10:28
that you're reassessing ensuring that the technique is effective for the
00:10:2800:10:32
patient that you're working on, and when it comes to all manual techniques,
00:10:3200:10:37
manipulations maybe more than any other, look for opportunities to get live
00:10:3700:10:42
education. Although I know videos are convenient and I'm happy to have these
00:10:4200:10:48
up for you to watch, it would be so much more helpful to use those videos as
00:10:4800:10:54
a recap of one-on-one attention with somebody who's experienced with
00:10:5400:11:00
manipulation techniques. At the very least grab a colleague, grab a friend and
00:11:0000:11:05
start practising these before you bring them into clinic and start using them on
00:11:0500:11:10
patients and clients. I hope you enjoyed this video, if you have any questions
