Distal Tibiofibular Joint Anterior to Posterior Manual Mobilization

Distal Tibiofibular Joint Anterior to Posterior Manual Mobilization is physical therapy technique used to address joint discomfort and restore range of motion in the lower leg. This technique provides focused pressure to the distal tibiofibular joint, which is located below the knee at the end of the lower leg. Manual mobilization helps to improve movement and reduce pain by stretching the joint capsule and releasing tension around the joint. This technique can be used to treat a variety of path

Transcript

00:00:0500:00:07
This is Brent of the Brookbush Institute, and in this
00:00:0500:00:07
video we're going to go over a joint
00:00:0700:00:11
based manual therapy technique. If you're watching this video I'm assuming you're
00:00:1100:00:14
watching it for educational purposes, and that you are a licensed professional
00:00:1400:00:20
with joint based techniques within your scope. That means osteopath's, chiropractors,
00:00:2000:00:24
physical therapists, you're probably all in the clear. Physical therapy assistants,
00:00:2400:00:28
athletic trainers, massage therapist's, you need to check with your governing body
00:00:2800:00:32
in your state or region to see whether this is within your scope of practice.
00:00:3200:00:36
Personal trainers this is definitely not within your scope of practice. Of course
00:00:3600:00:41
all professions could use this video for purely educational purposes to help with
00:00:4100:00:46
learning biomechanics, anatomy and of course palpation. In this video we're
00:00:4600:00:50
going to do an anterior to posterior fibula tibia mobilization, that's the
00:00:5000:00:53
distal tibiofibular joint. I'm going to have my friend Melissa come out, she's
00:00:5300:00:57
going to help me demonstrate. Now this technique makes a great ancillary
00:00:5700:01:00
technique to a technique we did in a previous video, which was the anterior to
00:01:0000:01:05
posterior talus on tibia mobilization. The hypothesis being that the lateral
00:01:0500:01:10
malleolus or distal fibula, has to follow the talus posteriorly as we dorsiflex
00:01:1000:01:14
the ankle. So with that being said, although we want to do a passive
00:01:1400:01:18
accessory motion exam and make sure that we have arthrokinematic stiffness
00:01:1800:01:22
in the direction that we're trying to mobilize, you might also do this
00:01:2200:01:28
technique as a means of maintaining, or trying to gain optimal dorsiflexion. Now
00:01:2800:01:33
the position you're going to be in for this technique is going to be foot on
00:01:3300:01:38
thigh; and the reason being is I want to be able to control dorsiflexion with my
00:01:3800:01:42
thigh, and have both hands-free for this mobilization. I need one hand to
00:01:4200:01:46
stabilize the tibia, and the other one to actually mobilize the fibula. You guys
00:01:4600:01:50
can see here just by leaning forward I can actually push Melissa into a
00:01:5000:01:55
few degrees of dorsiflexion. I can even control eversion and inversion a little
00:01:5500:02:01
bit just by swaying, to make sure she's neutral. The palpation portion of this is
00:02:0100:02:06
not totally complicated, but it is important that you guys kind of look
00:02:0600:02:12
over your Anatomy, and you practice putting your hands down on the ankle and
00:02:1200:02:17
trying to identify that Anatomy, specifically the lateral malleolus. For
00:02:1700:02:20
this technique it's important that you not
00:02:2000:02:26
only can find the lateral malleolus, but that you know the contours and edges of
00:02:2600:02:31
the lateral malleolus. So find your lateral malleolus, find the bottom of the
00:02:3100:02:35
lateral malleolus. So make sure you can feel that, go ahead and go to the
00:02:3500:02:40
posterior part of the lateral malleolus, and you should feel a groove in the back
00:02:4000:02:44
of the lateral malleolus, where your fibularis tendon runs through, and you
00:02:4400:02:48
might be able to feel that a little bit. Go to the front of the lateral malleolus
00:02:4800:02:53
and you'll notice that you run into a couple of tendons, those are the tendons
00:02:5300:03:01
of your long toe extensors, but if you press into that soft tissue just a
00:03:0100:03:05
little bit, you might be able to feel the joint line. Now the joint line is a nice
00:03:0500:03:11
thing to feel for this technique, because what we want to see is does the fibula
00:03:1100:03:16
move a little bit on the tibia, that's all we're trying to feel, does the fibula
00:03:1600:03:24
wiggle. If we have no wiggle we need to mobilize, if we have lots of wiggle then
00:03:2400:03:28
we don't want to mobilize. This joint the research kind of shows has one of two
00:03:2800:03:35
propensities right, either gets stiff or it becomes hypermobile. It's important
00:03:3500:03:39
that if we feel hypermobility, you feel more than a millimeter of motion here,
00:03:3900:03:43
it's really easy to wiggle this joint, this is not a technique you're going to
00:03:4300:03:51
do. Now if you feel good about your palpation, and you try to move the fibula
00:03:5100:03:56
it doesn't seem to move, that's a good sign that you have stiffness and that
00:03:5600:04:00
you probably should mobilize. It's really that simple, we don't need to get into
00:04:0000:04:06
grades of stiffness or anything, it's just does it feel like it barely moves
00:04:0600:04:15
or does it wiggle a lot. If it wiggles a lot, don't do this. Now once you felt
00:04:1500:04:20
the motion of the fibula, and you guys can see here I'm just kind of lifting it
00:04:2000:04:26
with these fingers, pushing it down with these fingers trying to kind of get my
00:04:2600:04:32
hands like right up against the joint line, maybe put the rest of my hand on
00:04:3200:04:39
the tibia here so that I can feel the amount of motion I have. Now Melissa's a
00:04:3900:04:44
little stiff. I would not do the mobilization with that same hand
00:04:4400:04:49
position guys. It's a little hard to feel how much movement you have with the
00:04:4900:04:53
technique I'm going to show you, but using your fingertips to do
00:04:5300:04:59
mobilizations just leads to pain. Just pushing your thumb down into this bony
00:04:5900:05:05
prominence is going to make somebody cringe. You have to be careful alright,
00:05:0500:05:10
trying to do something like this, is not a great idea. What we're actually going
00:05:1000:05:15
to do is use our thenar eminence here, try to get as much surface area on the
00:05:1500:05:19
lateral malleolus as we possibly can. What that usually ends up leading to is
00:05:1900:05:23
we we do a little bit of mobilization, and then we check with our fingertips,
00:05:2300:05:28
and we do a little mobilization, and then we check with our fingertips. So
00:05:2800:05:33
again how are we going to do this technique? We're going to use our thenar
00:05:3300:05:38
eminence, we're going to come over the top of our lateral malleolus. Now my
00:05:3800:05:44
suggestion is, is as you do this you're going to pick up a little bit of skin,
00:05:4400:05:50
before you press down. Alright so you guys I'm kind of smooshing some skin up
00:05:5000:05:55
this way, before I push down this way. The reason being is if I grab a bunch of
00:05:5500:05:59
skin and then pull down this way I stretch the skin out, and then I go to
00:05:5900:06:02
push down and it stretches the skin even more, and that becomes really
00:06:0200:06:05
uncomfortable. We want this to be as comfortable as possible otherwise
00:06:0500:06:09
they're going to guard and this technique is going to be really really challenging.
00:06:0900:06:14
Now the other contraindication that you have to be aware of, is you can really
00:06:1400:06:18
send a nice little shock up somebody's leg, give somebody a nice little burn,
00:06:1800:06:24
give somebody a really intense pinch by getting on that peroneal nerve. Of course
00:06:2400:06:29
if you do that this nerve is not gigantic, it's it's very very narrow,
00:06:2900:06:33
we're talking like a millimeter wide so you should be able to move your hand
00:06:3300:06:39
around and get off it pretty easy. So I'm going to take my hand here, I'm going to
00:06:3900:06:44
wrap it around Melissa's calcaneus, I'm going to make
00:06:4400:06:48
sure that calcaneus is off the table so that I don't crunch my hand when I
00:06:4800:06:54
start pushing down. I'm then going to grab a little bit of skin, just kind of
00:06:5400:07:00
slide my hand up this way, then put my thenar eminence over the top of her
00:07:0000:07:05
lateral malleolus, I'm going to kind of push her into dorsiflexion, this hand I'm
00:07:0500:07:11
going to stabilize her tibia with, and then I'm going to use, you guys notice
00:07:1100:07:17
I'm leaned forward here again, I'm just going to use my bodyweight to rock into
00:07:1700:07:23
this mobilization. Now I mentioned in previous videos I'm a Maitland certified
00:07:2300:07:28
orthopedic manual therapist, the protocols I know are the grades 1, 2, 3 &
00:07:2800:07:36
4. Grade 3 & 4 being at 50% between the initial resistance and end of arthro-
00:07:3600:07:42
kinematic range. If you guys have a different protocol that's fine, just make sure that
00:07:4200:07:45
you are disciplined about using that protocol, that you assess, address and
00:07:4500:07:51
reassess. If I went through this with my protocol, I'm going to go through
00:07:5100:07:56
everything I just told you, grab the calcaneus, take up some skin, push down on
00:07:5600:08:02
that lateral malleolus, ask my client did you, in any pain? This comfortable? Okay
00:08:0200:08:06
I'm going to find that first resistance barrier, once I find that first
00:08:0600:08:11
resistance barrier I'm going to start testing down, watching my clients face
00:08:1100:08:16
making sure she doesn't cringe on me, until I find the end. Notice that as I'm
00:08:1600:08:23
pushing down I have Melissa in at least neutral dorsiflexion with my thigh, so I
00:08:2300:08:29
have good control of her foot and ankle, and then once I find first resistance
00:08:2900:08:37
barrier, I find the end, I back off to 50%, now I'm just going to do 1 to 2
00:08:3700:08:45
set, 1 to 2 pulses per second until I feel a change in arthrokinematic
00:08:4500:08:50
stiffness. Now I mentioned a little earlier in this video, that is tough to
00:08:5000:08:54
feel with my thenar eminence, chances are I'm going to go back and check with
00:08:5400:09:00
my fingertips to see if I got an increase in range of motion.
00:09:0000:09:09
That's arthrokinematic range-of-motion though. So we'll do this for 30 seconds, and then
00:09:0900:09:14
I'm just going to use my fingertips here, did I get more range? If I got more range
00:09:1400:09:19
great, if I didn't I might go back and do another set, or another two sets, and then
00:09:1900:09:21
of course I'm going to want to follow this up with something a little bit more
00:09:2100:09:26
reliable than passive accessory motion exam, maybe I do my dorsiflexion
00:09:2600:09:32
goniometery. Alright so to go through hand position one more time, or body
00:09:3200:09:39
position and hand position; foot on thigh, neutral or slightly dorsiflexed, this
00:09:3900:09:44
hand's going to cup the calcaneus, pick up just a little bit of skin just kind
00:09:4400:09:49
of sliding up the side of the ankle here, and then press down over the front of
00:09:4900:09:54
the lateral malleolus, this hand is going to stabilize the tibia, and then I'm just
00:09:5400:10:00
going to find 50% between initial resistance and end of arthrokinematic
00:10:0000:10:08
range, back off to 50. I'm going to do my, this is going to be a grade 3 here
00:10:0800:10:15
alright. So I'm going to take up almost back to zero in resistance and down into
00:10:1500:10:24
50%. See if I can get a change in stiffness, check with my fingers. If I feel
00:10:2400:10:28
like I've got a change in stiffness maybe I'd follow that up with a dorsiflexion
00:10:2800:10:32
range of motion for goniometery, or maybe more of like a functional
00:10:3200:10:35
assessment like the overhead squat assessment. So in our close-up recap
00:10:3500:10:39
you'll notice my thighs against Melissa's foot here so that I can
00:10:3900:10:45
control dorsiflexion as well as eversion and inversion, and you can see
00:10:4500:10:49
her lateral malleolus right here. Now of course to assess this joint I
00:10:4900:10:54
talked about just using the fingertips, getting your thumb kind of on the joint
00:10:5400:11:00
line here. So if I start on her lateral malleolus and then fall off pushing the
00:11:0000:11:05
tendons of her long toe extensors over, I can kind of feel the joint line and then
00:11:0500:11:10
I'll usually just take these few fingers and kind of push up while my thumb
00:11:1000:11:15
pushes down, see if there's any wiggle there; and then here's the really
00:11:1500:11:20
important point that I was trying to make in the the further away shot, is as
00:11:2000:11:25
you're going to mobilize this joint it's important that you kind of slide your
00:11:2500:11:30
hand up this way, and you can see how her skin kind of crunches up, so that when I
00:11:3000:11:34
press down her skin is back to its normal length, whereas if I pull down
00:11:3400:11:41
from here, you can see I stretch out her skin trying to get pressure over the
00:11:4100:11:48
anterior surface of her lateral malleolus. Now I'm going to come up like this, press
00:11:4800:11:53
down, ask Melissa if she feels any pain, if she feels any tingling burning right,
00:11:5300:11:58
we don't want to stretch that nerve. I can use the other hand to stabilize her
00:11:5800:12:05
tibia, and then I can kind of find my resistance point, so first resistance end
00:12:0500:12:10
of arthrokinematic range, and then of course all of our mobilization protocols
00:12:1000:12:15
end up somewhere in the middle. I'll go from zero to 50% and a little larger
00:12:1500:12:21
amplitude doing my grade three. I'll go for thirty seconds until I think I feel
00:12:2100:12:28
a change in stiffness, and then I can go back to my assessment position of
00:12:2800:12:34
feeling the joint line, seeing if I got any wiggle back. Alright guys so get
00:12:3400:12:40
familiar with your lateral malleolus, feel all of its surfaces, find the the
00:12:4000:12:46
inferior border, find the anterior border, try to feel that joint line, really try
00:12:4600:12:50
to grab ahold of it with your fingertips, gently of course, so you don't hurt your
00:12:5000:12:54
patient, client, or partner you're practicing on. Stabilize the tibia with
00:12:5400:13:00
one hand, pick up a little tissue, make sure you follow through on your
00:13:0000:13:06
protocols, and of course at the end of your technique make sure you assess. So
00:13:0600:13:10
there you have it; assess, address, reassess. Make sure that
00:13:1000:13:14
every time you choose a joint based manual therapy technique it is based on
00:13:1400:13:18
an assessment, and that you return to that assessment after you've finished
00:13:1800:13:23
the intervention to see if it was effective for the individual, the patient
00:13:2300:13:27
or clients that you had in front of you. Ensure that you continue to
00:13:2700:13:31
learn your Anatomy because your Anatomy is going to help you with your hand
00:13:3100:13:37
placement, with understanding what a joint can do, with understanding what you
00:13:3700:13:43
may gain from this particular technique, and of course practice. You have to
00:13:4300:13:47
practice these techniques, hopefully not for the first time on a patient or
00:13:4700:13:52
client who just walked in the door. If you can find a more senior instructor or
00:13:5200:13:58
mentor to give you some really good hands-on instruction, use your peers for
00:13:5800:14:06
some good feedback, and of course always look for live education to help with
00:14:0600:14:10
your manual therapy techniques. I know these videos make education very
00:14:1000:14:16
convenient, but there is no substitute for learning manual therapy in a live
00:14:1600:14:20
setting. I look forward to talking to you guys again soon.
