This is Brent of the Brookbush
00:00:0400:00:07
Institute, and in this video we're bringing
00:00:0700:00:09
you another manual technique. Now if you're watching this video I'm assuming
00:00:0900:00:13
you're watching it for educational purposes, and that you are a licensed
00:00:1300:00:17
manual therapist following the laws regarding scope of practice in your
00:00:1700:00:20
state or region. That means athletic trainers, chiropractors, physical
00:00:2000:00:25
therapists, osteopaths, licensed massage therapists you are likely in the clear
00:00:2500:00:30
to do these techniques. Personal trainers this probably does not fall within your
00:00:3000:00:33
scope of practice, although you might be able to use the palpation portion of
00:00:3300:00:38
this video to aid in learning your functional anatomy in an educational
00:00:3800:00:43
setting, supervised by a licensed manual therapist. Now before we place our hands
00:00:4300:00:48
on a patient or client it is important that we assess and have a good rationale
00:00:4800:00:53
for doing so, and of course if we're going to assess then we should be
00:00:5300:00:57
reassessing to ensure that the manual technique we're using is effective, and
00:00:5700:01:01
we have a good rationale for continuing to use that technique. In this video were
00:01:0100:01:04
going to go over static manual release of the erector spinae muscle. I'm going
00:01:0400:01:06
to have my friend Melissa come out, she's going to help me demonstrate. We're going
00:01:0600:01:10
to use the same palpate and compress technique we've been using for all of
00:01:1000:01:14
our static manual release videos, using that that four-step process of
00:01:1400:01:18
differentiating, knowing where our common trigger points are, knowing what not to
00:01:1800:01:21
press on, and of course getting our patient inclined in good position and us
00:01:2100:01:25
in good position so that we have good technique. Starting with a
00:01:2500:01:30
differentiation of tissues your erector spinae are fairly superficial, and
00:01:3000:01:34
providing we're not talking about trying to differentiate the various erector
00:01:3400:01:40
spinae muscles, they're actually not that hard to palpate. The three muscles
00:01:4000:01:47
combined create a column of tissue on either side of the spine. I think you
00:01:4700:01:51
guys instinctually knew this right. this this valley is created by the skin and
00:01:5100:01:56
underlying fascia being tacked down to the spinous process, and then the
00:01:5600:02:02
thoracolumbar fascia and fascia along the spine here, all the way
00:02:0200:02:08
into like our cervical thoracic fascia create these columns wrapping around the
00:02:0800:02:15
erector spinae muscles that create hills on either side for our palpation. The
00:02:1500:02:20
only thing we have to consider outside of knowing where these hills are, is what
00:02:2000:02:25
direction of a diagonal these fibers go in, because we're going to want to go
00:02:2500:02:31
back to that stroke perpendicularly to find the densest fascicles, and then go
00:02:3100:02:37
parallel along the dense fiber to find the nodule hyperactive point,
00:02:3700:02:43
trigger point. Alright so here's how the diagonals work. most of the erector
00:02:4300:02:49
spinae, in fact all of the erector spinae have a diagonal that goes from lumbar
00:02:4900:02:55
spine essentially to shoulder. If you think in that direction from inferior
00:02:5500:03:00
medial to superior lateral, and then you just drew parallel lines in your head,
00:03:0000:03:05
that's the direction of the erector spinae. The only muscles that are a
00:03:0500:03:08
little different being erectors of the spine that can
00:03:0800:03:14
also develop trigger points is our multifidi, our trigger points for our
00:03:1400:03:18
multifidi are usually in our lumbar spine here is what we're talking about, and
00:03:1800:03:25
they go in the other direction. They go from inferior lateral to superior medial.
00:03:2500:03:33
If I'm going to palpate tissues that run this way again so we're back to a erector
00:03:3300:03:38
spinae, I'm going to set up my hips so they're even with Melissa's hips and
00:03:3800:03:44
then my hands are going to be going in the direction of Melissa's head, and that
00:03:4400:03:49
would be my perpendicular stroke. So that's not too bad. When I do my erector
00:03:4900:03:59
spinae I'm facing this way, and then I can just survey the length of my erector
00:03:5900:04:01
spinae. I'm just kind of picking up my hand,
00:04:0100:04:05
strumming over the tissues. Now it helps to know where your trigger points are.
00:04:0500:04:10
Your two common trigger points that we're usually releasing in the erector
00:04:1000:04:15
spinae are right in the middle of the lumbar spine, like in line with somewhere
00:04:1500:04:20
between l2 and l4, and then just above the thoracolumbar junction there tends
00:04:2000:04:26
to be another trigger point. So if I know that I might go right to those points
00:04:2600:04:33
first just to see if I can narrow this this search down a little
00:04:3300:04:38
bit, and when I find really dense fascicles again, I'm then going to go in
00:04:3800:04:48
line with a fiber, search the whole fiber here for a nodule and acute point of
00:04:4800:04:52
density and acute point of overactivity, And then you guys can use one of your
00:04:5200:04:57
various comfortable hand grips either thumb over thumb just again leaning in,
00:04:5700:05:03
you can use the technique I like to use as you guys know which is kind of
00:05:0300:05:07
having that dummy thumb underneath, or putting my pisiform hamate over my thumb,
00:05:0700:05:13
or putting my thumb in my thenar groove here. So in this case what I'm
00:05:1300:05:21
going to do is pisiform hamate, and I'm just going to hold 30 seconds to two minutes
00:05:2100:05:27
to kind of pin down the tissue. Notice I am I'm not pushing straight
00:05:2700:05:31
down, I'm kind of pushing this way, that does help to keep me from playing that
00:05:3100:05:35
game of like put your finger on top of a marble just and it just like keeps
00:05:3500:05:41
shooting out this way. I tend to not only push down but push a little bit so
00:05:4100:05:46
that I'm kind of like bowing this tissue this way, which holds that trigger point
00:05:4600:05:54
underneath my thumb. Now if I want to switch around and do the multifidus,
00:05:5400:05:57
maybe I have done all of my erector spinae,
00:05:5700:06:02
I'm then going to put my hips level with Melissa's shoulders, and I'm now facing
00:06:0200:06:07
her opposite hip. I can then go through, and guys these are going to be
00:06:0700:06:12
lumbar spine right, otherwise as we get up in the thoracic spine the multifidus
00:06:1200:06:17
are not well developed in the thoracic spine, and of course when we we do the neck that's a
00:06:1700:06:20
whole different set of techniques which we talked about in different video. So if
00:06:2000:06:26
we're doing multifidus it is going to be lumbar spine. We're going to go this way,
00:06:2600:06:35
this direction, a little closer to our spinous process until we find an acute
00:06:3500:06:40
point of overactivity or density. It does help to kind of bring the pants down a
00:06:4000:06:43
little bit, so that you don't have to feel through another
00:06:4300:06:47
layer of clothing right. You already have the skin to feel through, you already
00:06:4700:06:52
have some adipose tissue fascia, there's a lot going on back here that we
00:06:5200:06:57
got to feel through to just feel these small increases in tissue density. And in
00:06:5700:07:03
fact, the common trigger point here is actually somewhere between, in that
00:07:0300:07:11
little divot between our PSIS and then the spinous process of l4 l5. Like right
00:07:1100:07:18
in here there's like a very common trigger point, all right so if I push in
00:07:1800:07:24
there, how does that feel Melissa? Yeah a little a little tender. This is
00:07:2400:07:34
definitely a common trigger point. As far as is there anything in this area that
00:07:3400:07:40
maybe we shouldn't put our hands on, well no if providing that we're staying close
00:07:4000:07:46
to the vertebral column, our transverse processes for the most part protect us
00:07:4600:07:49
from being able to do damage to things that would be deeper and more sensitive.
00:07:4900:07:56
It would be pretty hard for example for me to push down so hard that I damaged a
00:07:5600:08:02
nerve or damaged an internal organ. Like you'd have to be way out here to
00:08:0200:08:06
get to some of your internal organs, and I know people worry about that, but the
00:08:0600:08:10
transverse processes protect us pretty well. Of course if somebody was or had
00:08:1000:08:15
acute lumbar pathology like a nerve root adhesion that was kind of new. Or they
00:08:1500:08:19
were experiencing some pretty significant sciatic symptoms, or you had
00:08:1900:08:26
like a lumbar herniation, obviously be careful. Don't go in and push
00:08:2600:08:32
down as hard as you possibly can. It's not so much that this is one of those
00:08:3200:08:36
things that you need to watch where you put your hands, but maybe how you put
00:08:3600:08:40
your hands. If I knew somebody was very sensitive to posterior to anterior
00:08:4000:08:44
pressure I might even bring the table up a little
00:08:4400:08:55
higher, so that I can get a little bit more of a horizontal pressure
00:08:5500:09:02
so that I'm not getting so much of this. We can still pin tissues pretty good by
00:09:0200:09:09
pushing them towards the spinous process. how does that feel Melissa? It's still very tender, of
00:09:0900:09:13
course she has no lumbar pathology that we need to worry about, but you guys can
00:09:1300:09:19
kind of imagine how this would be helpful. Back to client position,
00:09:1900:09:26
notice when I wanted a more horizontal direction I raised the table, when I want
00:09:2600:09:30
a more vertical direction of course I'm going to lower the table. What you don't
00:09:3000:09:35
want to do and this is just if you think about it some common sense, you don't
00:09:3500:09:37
want a high table and trying to be pushing down,
00:09:3700:09:43
we don't want arms like this. We want arms straight. We want to use our fingers
00:09:4300:09:48
maybe to palpate just because we need that sensitivity, but then when we
00:09:4800:09:52
palpated the tissue that we need and we're just applying pressure, we
00:09:5200:09:56
really want to apply pressure not with hand strength and arm strength, but just
00:09:5600:10:02
by weaning our body and using body weight. I'm actually not using any
00:10:0200:10:07
strength at all here. My elbows are just shy of lock, my arms are nice and
00:10:0700:10:14
straight, and I push down, I can tell you guys this is where having mirrors in
00:10:1400:10:19
your office comes in handy. I know not everybody has that, but if you have
00:10:1900:10:22
mirrors in your office check your own posture every once in a while. I know we
00:10:2200:10:26
put mirrors and offices for assessments of our patients, but I think sometimes we
00:10:2600:10:33
need as much assessment on our technique and posture while we work. Alright so
00:10:3300:10:38
just a real quick recap guys, common trigger points just above the
00:10:3800:10:43
thoracolumbar junction right in the middle of the lumbar spine, and then in
00:10:4300:10:50
that little soft area between the PSIS and spinous process of l4 l5 usually a
00:10:5000:10:55
multifidus trigger point, Eerector spinae perpendicular strokes are this way,
00:10:5500:11:02
because those fibers run this way multifidus run this way, so we set up
00:11:0200:11:06
this way. Stay tuned for a close-up recap. You guys
00:11:0600:11:09
can see the trigger points I've marked out, here are the most common trigger
00:11:0900:11:13
points in the erector spinae and the multifidus. One just above the
00:11:1300:11:17
thoracolumbar junction the other right in the middle of the lumbar spine, and
00:11:1700:11:21
then of course that multifidus trigger point often occurs right between the
00:11:2100:11:28
PSIS and the spinous process of l4 l5 and that soft tissue divot there. Now if
00:11:2800:11:33
we're going to palpate and release the erector spinae, because they had a
00:11:3300:11:39
inferior medial to superior lateral diagonal, I want to line my hips up with
00:11:3900:11:44
Melissa's hips, and then my hands are kind of going in the direction towards
00:11:4400:11:53
her opposite shoulder. I'm going to do my perpendicular strokes, strumming these
00:11:5300:11:58
fibers just like guitar strings, looking for the densest or tensest guitar
00:11:5800:12:05
strings. Once I find the densest tissues, I then go along the length of that
00:12:0500:12:10
tissue to see if there's any sort of nodule or acute point of hyperactivity, a
00:12:1000:12:16
trigger point, once I find that point then I can go -the palpating thumb
00:12:1600:12:21
becomes my dummy thumb, and I can just place either my thenar groove
00:12:2100:12:26
over that thumb, or my pisiform hamate over that thumb. Straighten out my arms,
00:12:2600:12:32
lean in, apply pressure for thirty seconds to two minutes. Once I get a
00:12:3200:12:36
release there, then maybe I keep palpating, keep strumming all these
00:12:3600:12:40
fibers looking for any other shorter points. You have to remember that your
00:12:4000:12:44
erector spinae is made up of tons of fascicles
00:12:4400:12:49
right that all run in parallel this way. So it is possible to have multiple
00:12:4900:12:53
trigger points in multiple different levels these are simply the most common
00:12:5300:12:58
trigger points. Now for the multifidus remember that instead of going this way,
00:12:5800:13:05
since the multifidus go superior medial to inferior lateral, I have to go this way,
00:13:0500:13:11
that I have to turn myself around, so now my hips are in line with Melissa's
00:13:1100:13:15
shoulders, my hands going towards her opposite
00:13:1500:13:21
hip, and it's a little different palpation, it's a little different feel than these
00:13:2100:13:27
big erector spinae muscles. The multifidus are usually a little flatter. But
00:13:2700:13:34
you're going to look for the densest fascicles. Once you find them, once again we'll go along that
00:13:3400:13:41
fascicle to find any tender nodule, and then once I find it, I can either do my
00:13:4100:13:49
thumb over thumb, pisiform hamate over thumb, or a my I can even do thenar
00:13:4900:13:54
groove over thumb like this, holding for 30 seconds to two minutes, until I get a
00:13:5400:13:58
release. So there you have it, knowing your functional Anatomy will definitely
00:13:5800:14:01
help your manual technique. It'll help you differentiate structures so that you
00:14:0100:14:05
can place your hands where they need to be, as well as make you aware of these
00:14:0500:14:09
sensitive structures around the tissue that you're trying to target. Things like
00:14:0900:14:13
nerves and lymph nodes, and arteries. Make sure that if you're going to place your
00:14:1300:14:17
hands on a patient that you have done an assessment and have a good rationale for
00:14:1700:14:21
placing your hands on that patient, and if you're going to assess make sure you
00:14:2100:14:25
reassess to ensure that your technique was effective, and you have a good
00:14:2500:14:31
rationale for using that technique again. Now with manual therapy, one on one live
00:14:3100:14:36
education is incredibly important, please be looking for opportunities like
00:14:3600:14:42
workshops and mentorships, and maybe even classes at your local university, that
00:14:4200:14:47
can get you some one-on-one individual instruction or at least some live
00:14:4700:14:54
classroom instruction, so you've had a chance to be critiqued and mentored by
00:14:5400:14:58
somebody senior to you with some experience in manual therapy techniques.
00:14:5800:15:04
And before you bring this stuff back to your rehab, fitness or performance
00:15:0400:15:11
setting, please practice on colleagues. There is no substitute for practice and
00:15:1100:15:16
it is going to take a while to get accustomed to some of the techniques
00:15:1600:15:20
that we show in these manual technique videos, don't expect to learn them in two
00:15:2000:15:26
or three, or even five minutes. You want to have hours of experience under your
00:15:2600:15:30
belt, working on various different body sizes and shapes, so
00:15:3000:15:34
that when you do get that first paying client, first paying customer then you're
00:15:3400:15:40
really trying to make a good positive impact, really trying to promote better
00:15:4000:15:45
outcomes, you feel comfortable with that technique. I look forward to hearing
00:15:4500:15:49
about your outcomes and hearing your questions in the comments section of
00:15:4900:15:53
this video. I'll talk with you soon.
