Goniometry Hip External Rotation (in Prone)
Goniometry Hip External Rotation (in Prone) is an assessment of the range of motion of the hip when the leg is taken towards the back and rotated away from the midline of the body. This assessment can help provide an insight into hip mobility and can help identify any potential hip mobility limitations or any potential issues with the hip joint. The assessment is performed in a prone position with the hip joint flexed to 90 degrees and the leg extended and rotated away from the body as
Transcript
00:00:0500:00:10
This is Brent the Brookbush Institute
00:00:0500:00:10
at the Independent Training Spot going
00:00:1000:00:15
over a hip goniometry. So in this video we're doing hip external rotation
00:00:1500:00:19
in that prone position, and I promise in this video I'm going to talk about why i
00:00:1900:00:23
chose the prone position as opposed to that seated position we see in Norkin and
00:00:2300:00:26
and White. I'm going to have my friend Jordan Tisdale come out, great trainer
00:00:2600:00:31
here at the Independent Training Spot. He's let me tape up his legs despite the
00:00:3100:00:35
fact that it might hurt his legs, because of the hair when I take this off.
00:00:3500:00:41
Nonetheless almost the same exact setup as the hip internal rotation in prone.
00:00:4100:00:47
Alright my stabilization arm, that's the one attached to the protractor, is
00:00:4700:00:50
going to be perpendicular to the table, and you guys can see to create a
00:00:5000:00:55
little bit more consistency, I put a big piece of orange Rock tape right through
00:00:5500:01:01
the middle of his patella, to his tibial tuberosity. So that line that I've
00:01:0100:01:05
created, I know I can keep going back to, over and over and over again, and be
00:01:0500:01:11
really really consistent so that if I reassess, I know how much change I've
00:01:1100:01:15
made. Now external rotation we're going to do very similar to hip internal
00:01:1500:01:23
rotation. I'm going to have him find his end range here, notice when i go
00:01:2300:01:26
to find his end range to start, regardless of knowing that i'm going to
00:01:2600:01:30
measure down here, i need to stabilize his pelvis, because i'm sure you guys can
00:01:3000:01:35
see if I just tip him this way, you can see this side of his pelvis just kind of
00:01:3500:01:39
rides up. I want to make sure that doesn't happen because that's adding
00:01:3900:01:47
degrees of motion. Alright so I take him here, find his end range, there it is. I
00:01:4700:01:55
have Jordan hold it, go ahead and hold for me. Go ahead and set up my
00:01:5500:02:00
stabilization arm, alright perpendicular to the table. Movement arm right through the
00:02:0000:02:10
middle of that line, and Jordan has 55 degrees range of motion. Now normal would
00:02:1000:02:18
be 40 to 50, so Jordan here is a little hypermobile. A thing to consider guys is
00:02:1800:02:25
it's just as dangerous, or just as injury provoking or just as outside the norm to
00:02:2500:02:30
be hypermobile, as it is to be hypomobile. So I'm going to go ahead and do
00:02:3000:02:34
this one more time, this will help you guys review and see it one more time, but
00:02:3400:02:38
I also want to make sure I got this measurement accurate, because the
00:02:3800:02:42
hypermobility is not the most common thing in the world. So once again i'm
00:02:4200:02:47
going to stabilize this pelvis, take him to his end range where i get that nice normal
00:02:4700:02:51
firm end feel. I'm going to have them hold that for me, go ahead and hold that
00:02:5100:02:58
Jordan. Set up my stabilization arm, set up my movement arm, and like I said if I'm
00:02:5800:03:01
going to be truly accurate, i'm actually going to get down so that I am eye level
00:03:0100:03:08
with my goniometer. Make sure I can see it accurately. Make sure my stabilization
00:03:0800:03:10
arm is set up.
00:03:1100:03:19
And this time when I got down on the goniometer here I see 50 degrees. So that
00:03:1900:03:25
is normal, thanks Jordan. Now once again we have to go through what does this
00:03:2500:03:30
mean. Well first off let's talk about the restrictions, let's talk about passive
00:03:3000:03:35
range of motion, 40 to 50 degrees. Let's say I got 30 degrees, what would that
00:03:3500:03:41
mean? Well I need to think towards techniques that I could use to get him
00:03:4100:03:46
back to 40 to 50 degrees range of motion. So what are the muscles that would
00:03:4600:03:51
restrict external rotation, that be my internal rotators, specifically those
00:03:5100:03:57
overactive internal rotators, the TFL, gluteus minimus, not gluteus medius, but
00:03:5700:04:02
gluteus minimus, and anterior adapters. So i might do all of my release and
00:04:0200:04:08
lengthening techniques here, what about fascial components, anterior joint capsule.
00:04:0800:04:14
You guys notice I have a star by this, originally when I measured Jordan I saw
00:04:1400:04:19
55 degrees, I saw a little hyperpermobility. That's not totally uncommon
00:04:1900:04:24
for this goniometric assessment. Now what it could mean though is that I have
00:04:2400:04:30
too much laxity, and I think we have a tendency to see too much laxity or too
00:04:3000:04:36
much mobility in this range of motion, because the anterior joint capsule has a
00:04:3600:04:41
tendency to get lax. If we go back through all of that postural dysfunction
00:04:4100:04:44
stuff, when we start looking at like lumbo-pelvic hip complex dysfunction, SI
00:04:4400:04:50
joint dysfunction, we start looking at just what the hip does arthrokinematically.
00:04:5000:04:55
It has a tendency to move anterior and superior, which stretches
00:04:5500:04:59
out that anterior joint capsule a little bit. Now the thing that's supposed to be
00:04:5900:05:03
restricting our range of motion and keeping us for 40 to 50 degrees is
00:05:0300:05:09
actually loose, and allowing us to go further. So kind of keep that in mind as
00:05:0900:05:14
you're doing this assessment, the iliofemoral ligament, pubofemoral
00:05:1400:05:20
ligament, and anterior facia latae are also all things that could restrict our range
00:05:2000:05:23
of motion, so that might be something to think about.
00:05:2300:05:29
Like long passive stretching into internal rotation, or some of our
00:05:2900:05:32
instrument assisted soft tissue mobilization, some of our pin and stretch
00:05:3200:05:38
techniques. We do want to look at our joint of the hip itself, and do maybe
00:05:3800:05:43
some of our passive accessory mobilizations. So does he have normal
00:05:4300:05:48
posterior glide, can i distract his hip normally. Can I do that lateral
00:05:4800:05:53
distraction, does he have normal anterior glide, and once again coming back to the
00:05:5300:05:58
nervous system, you guys notice I set up this same graph for all of my goniometry,
00:05:5800:06:02
just so that I set up a systematic way for me to think through this stuff.
00:06:0200:06:07
Femoral nerve could be indicated, although this is not necessarily a
00:06:0700:06:12
femoral nerve test, and then quite possibly the lateral femoral cutaneous
00:06:1200:06:17
nerve. If I thought any of this, once again i'm going to do further neuro
00:06:1700:06:22
dynamic testing, so that I pinpoint where things are happening. Now in the
00:06:2200:06:27
beginning of both the hip internal rotation goniometry, and hip external
00:06:2700:06:31
rotation goniometry in prone, I mentioned that I don't particularly like
00:06:3100:06:36
the Norkin and White seated hip internal and external rotation goniometry.
00:06:3600:06:42
The reason being is my goal is to get to this right, I want to figure
00:06:4200:06:50
out what structures I'm going to actually do something to. My feelings on
00:06:5000:06:55
this seated position is more often than not, I'm restricted in internal rotation
00:06:5500:07:01
by a TFL that is put into such a shortened position, that it starts to
00:07:0100:07:06
spasm a little bit, or get really really overactive. People start cramping up, well
00:07:0600:07:11
now I have a test that only indicates potentially one structure. I don't know
00:07:1100:07:16
that I've actually hit the end range of that joint. I'm not sure that that just
00:07:1600:07:20
knowing that the TFL gets spastic in that position helps me. It doesn't
00:07:2000:07:24
necessarily help the person move better, and then in external rotation, generally
00:07:2400:07:29
people just start cramping in their adductors. So the range of motion that
00:07:2900:07:33
you'll get from those tests, there's actually research to show that whether
00:07:3300:07:39
you're prone, whether you're seated, whether you do hip 90 90, you get roughly
00:07:3900:07:44
the same ranges of motion. My question to you guys would be, is if you did find a
00:07:4400:07:47
restriction in the seated position, what would you do? As opposed to finding a
00:07:4700:07:54
restriction in this position, which to me I'm going to go after TFL, gluteus
00:07:5400:07:59
minimus. Most of the time that will relieve this restriction. That makes
00:07:5900:08:05
sense. In the other one we did right hip internal rotation, very very indicative
00:08:0500:08:12
of posterior capsule, piriformis and deep rotator tightness. So I have key
00:08:1200:08:17
structures. I'm going to go to in prone right, as opposed to that seated position,
00:08:1700:08:23
where I have a tendency to go. So you're TFL went into spasm, great that doesn't
00:08:2300:08:26
really tell me what I need to do in my intervention. So I hope that all makes
00:08:2600:08:31
sense to you guys. I hope by doing these assessments, explaining where i'm
00:08:3100:08:35
thinking, you guys will be able to use this test to improve your interventions.
00:08:3500:08:38
i look forward to hearing about your outcomes.
