Goniometry: Hip Internal Rotation at 90 Degree of Hip Flexion (90/90 Hip IR)

Goniometry: Hip Internal Rotation at 90 Degree of Hip Flexion (90/90 Hip IR) is an orthopedic test used to measure the range of motion of the hip joint. It is a combination of hip flexion with simultaneous hip internal rotation and is used to assess gluteal, external and rotator muscle strength as well as joint laxity and hip impingement. The patient is typically in a siting or supine position and the practitioner manually moves the

Transcript

00:00:0600:00:10
This is Brent of the BrookBush Institute
00:00:0600:00:10
at the Independent Training Spot going
00:00:1000:00:14
over our next goniometric assessment video, which is supine 90-90 hip
00:00:1400:00:19
internal rotation goniometry. Now I know what you're thinking we just went over
00:00:1900:00:24
internal rotation goniometry in prone. These are not the same assessment.
00:00:2400:00:28
They're both very commonly used, however what they're going to tell us about the
00:00:2800:00:33
hip and the restrictions at the hip is slightly different, and could give us a
00:00:3300:00:37
little bit more information to use when we create our intervention. I'm going to
00:00:3700:00:41
have my friend Melissa come out, she is going to help me demonstrate
00:00:4100:00:44
this goniometric assessment. Now the first thing we need to do is know where
00:00:4400:00:48
our two lines are right, where is the line for the stabilization arm, where is
00:00:4800:00:53
the line for the movement arm of our goniometer. Now stabilization arm is
00:00:5300:00:58
going to go straight through the midline, or a line parallel to the midline of
00:00:5800:01:01
Melissa's body here, or a line, you guys can think of a line that runs parallel
00:01:0100:01:06
to this table, the edge of this table. The movement arm, you guys can see I put a
00:01:0600:01:10
little tape here, the movement arm is going to go through the center of the
00:01:1000:01:13
knee, and line up with the tibial tuberosity. This is the same line we
00:01:1300:01:17
created in hip internal rotation in prone right. We don't want to just follow
00:01:1700:01:22
the tibia because the crest of the tibia isn't straight, so that could lead to
00:01:2200:01:27
some inaccuracy in our measurements. Now the way I like to do this guys is I like
00:01:2700:01:33
to to go ahead and put my goniometer down to start, bring Melissa's hip here
00:01:3300:01:38
in to 90 degrees, make sure her knee is directly over her hip, no adduction or
00:01:3800:01:44
abduction, no flexion or extension, just right at 90 degrees. I'm going to
00:01:4400:01:48
go ahead and take her into internal rotation until I get that firm end feel,
00:01:4800:01:52
which is the normal end feel at the hip. Alright this will be a
00:01:5200:01:58
slightly softer end feel than we felt in the prone hip internal rotation, but
00:01:5800:02:02
still a firm end feel nonetheless. I'm then going to have Melissa try to give
00:02:0200:02:06
me a little help, can you hold this position. This is not an easy position
00:02:0600:02:11
for her to hold, so what I'm going to do is once i got my goniometer and i got
00:02:1100:02:15
her kind of set up, I'm gonna wrap my arm around, i'm going to stabilize her leg,
00:02:1500:02:19
kind of reposition. Make sure i'm as accurate as possible, that her knee is
00:02:1900:02:24
directly over her hip, make sure she's at that end range, and then i'm going to go
00:02:2400:02:31
ahead and line up my stabilization arm here, get my movement arm lined up, and I
00:02:3100:02:37
got 36 degrees. So that's hip internal rotation goniometry
00:02:3700:02:41
at 90 degrees. Let me do that one more time for you guys, real quick just
00:02:4100:02:47
as I would do it in my own clinic. Hip flexion, no adduction or abduction. Good take
00:02:4700:02:51
her to her end range. Can you hold that for me Melissa, good. Make sure your not hip
00:02:5100:03:00
hiking for me. Good, setup my stabilization arm, my movement arm ,make
00:03:0000:03:10
sure I have, go ahead and relax, make sure she's all lined up, and that time I got
00:03:1000:03:16
38 degrees, good. If I wanted to be as accurate as possible I might take up to
00:03:1600:03:21
three measurements and average those, but you guys can see how this measurement is
00:03:2100:03:27
done. Now the next question is what do we do with it, thank you Melissa. Guys can
00:03:2700:03:34
see the board back here? Again if we're doing goniometric assessment, remember
00:03:3400:03:38
we have to assess for one of two reasons, we either assessing to clear our
00:03:3800:03:41
patients and clients, and make sure that they are prepared for intervention, that
00:03:4100:03:46
they're able to work with us, nothing's contraindicated, all right or we're
00:03:4600:03:52
trying to figure out what we're going to do in our intervention, in whether it's
00:03:5200:03:55
our exercise, or physical therapy, or athletic training, we need to figure out
00:03:5500:04:00
how we're going to affect this test that we just did. Goniometry is a
00:04:0000:04:03
flexibility assessment, so I need to think about what are the restrictions to
00:04:0300:04:08
this goniometric assessment. In the case of hip internal rotation at 90
00:04:0800:04:13
degrees this is a slightly confusing graph actually, we're going to start with
00:04:1300:04:19
muscles. Alright so the first thing that restricts hip internal rotation at 90
00:04:1900:04:23
degrees, and this is a puzzling one, it's probably your TFL and your gluteus
00:04:2300:04:26
minimus, and I know what some of you guys are thinking, some of you guys were up on
00:04:2600:04:31
your functional Anatomy, wait a second those are internal rotators, so how are
00:04:3100:04:36
they going to restrict hip internal rotation? And that's a great question and
00:04:3600:04:41
I'll give you guys my theory on that, which is the TFL and gluteus minimus can
00:04:4100:04:46
also superiorly and anteriorly glide the femoral head in the acetabulum.
00:04:4600:04:50
So we're probably seeing when we have somebody who's restricted in hip
00:04:5000:04:54
internal rotation, is we start getting a little bit of impingement on that
00:04:5400:04:58
capsule, or we start running out of room right where the the femoral head is
00:04:5800:05:03
rolling, but not gliding posteriorly enough. So we're going to release these
00:05:0300:05:10
muscles to actually help improve arthrokinematics. The next thing I'm
00:05:1000:05:15
going to go after is the adductors, now which adductor? Great question. Once we
00:05:1500:05:19
get into hip flexion at 90 degrees, we've lengthened the adductor Magnus, we've
00:05:1900:05:26
shortened the anterior adductors right, but both seem to be able to restrict
00:05:2600:05:31
this range of motion. So I'm going to go ahead and start releasing and thinking
00:05:3100:05:35
about stretching those adductors. The next thing I'm going to go after is the
00:05:3500:05:40
deep rotators, but for those of you guys were really really up on your
00:05:4000:05:44
kinesiology, you guys might remember that the piriformis above 90 degrees is
00:05:4400:05:49
actually a hip internal rotator. So it's not going to restrict this motion. So you
00:05:4900:05:56
guys got TFL and glute min, adductors and deep rotators are probably the first
00:05:5600:06:01
three muscles or three muscle groups that I'm going to go after. However don't
00:06:0100:06:06
count out the psoas and iliacus, biceps femoris, and rectus femoris, these could
00:06:0600:06:11
also contribute. Once I get through all of this muscle stuff, what if I still
00:06:1100:06:19
have restriction in the hip? Well probably the most impactful thing is
00:06:1900:06:22
when we get actual restriction in the joint capsule itself. So I'm going to
00:06:2200:06:26
start looking for posterior and inferior capsule shortening, and the techniques
00:06:2600:06:30
I'm going to use for that is either the self administered hip joint mobilization
00:06:3000:06:34
I did in a previous video, or we're going to have to look towards some of those
00:06:3400:06:37
manual techniques. I know you guys are familiar with like your lateral
00:06:3700:06:44
distraction, or your posterior glide of the hip. The sacroiliac joint, I think
00:06:4400:06:49
I've mentioned this in a couple videos since like the piriformis and some
00:06:4900:06:54
other structures cross that sacroiliac joint, through either a fascial connection
00:06:5400:06:58
or a direct connection. If that sacroiliac joint gets bound down, becomes
00:06:5800:07:02
dysfunctional, it could change the tonicity of muscles that cross both the
00:07:0200:07:09
sacroiliac joint and the hip, and affect our range of motion. So now I got all of
00:07:0900:07:13
these muscles I could think of working on. I got these two joints that I could
00:07:1300:07:17
think about working on. Don't forget about the fascial component alright, so my
00:07:1700:07:23
lateral fascia lata, as well as my posterior hip. All of you guys using your
00:07:2300:07:26
PIN and stretch techniques, and your instrument assisted soft tissue
00:07:2600:07:30
mobilization, and your self administered myofascial release, think towards these
00:07:3000:07:35
areas, and go well if I've already done the muscle stuff, and the hip stuff, maybe
00:07:3500:07:40
I need to work on that fascial component. And of course we also need to think
00:07:4000:07:46
nerves. Now goniometery is not a great assessment of which nerve is
00:07:4600:07:50
restricted, or whether we had a nerve restriction. The most important thing to
00:07:5000:07:54
remember is if I happen to be doing this, and Melissa had got paresthesia right,
00:07:5400:07:59
she had got that pins and needles feeling, the tingling down the
00:07:5900:08:06
back of her leg, do I have sciatic nerve impingement. So these deep rotators,
00:08:0600:08:09
one of them is my gemellus superior, and then i have my piriformis, on top of that
00:08:0900:08:14
my sciatic nerve runs between those two muscles. If I crank her into internal
00:08:1400:08:19
rotation, what I do is I tighten my gemellus superior, and pinch up on my
00:08:1900:08:23
sciatic nerve. Nerves that are normally functioning
00:08:2300:08:29
will not cause paresthesia. If she has a dysfunctional sciatic nerve for some
00:08:2900:08:33
reason and I impinge it, it's going to give her sensation, and I need to go
00:08:3300:08:37
ahead and move on to my neurodynamic tests. We might also have some sensation in
00:08:3700:08:43
the posterior femoral cutaneous nerve. So once again we had this huge complicated
00:08:4300:08:50
graph, so let me kind of break this down for you guys. I use this goniometric
00:08:5000:08:55
assessment probably more than any other assessment for the hip, and the reason
00:08:5500:09:02
being is is it gives me all of these potential ways to correct hip
00:09:0200:09:08
dysfunction, and what I find which is most important, is that if i can get hip
00:09:0800:09:15
internal rotation at 90 degrees back to optimal, that I've probably done a really
00:09:1500:09:21
good job at removing as many restrictions as I can at the hip. So
00:09:2100:09:24
while the prone hip internal rotation is nice and gives me a lot of great
00:09:2400:09:31
information, this is the one where I go okay if I got this one, I got them
00:09:3100:09:35
back to close to normal and I know I'm on the right track. I hope i just gave
00:09:3500:09:38
you guys a ton of information, a ton of things to think about, and i hope you
00:09:3800:09:42
guys understand hip internal rotation goniometry at 90 degrees of hip
00:09:4200:09:46
flexion. Thank you.
