Hip Flexion Goniometry
Hip Flexion Goniometry is a method of measuring the range of motion of the hip joint. It involves manually measuring the angle of the hip from a neutral position, usually with a goniometer. This testing helps to evaluate the function and flexibility of the hip, determine the cause of mobility problems, and provide effective treatment options. It is used to accurately diagnose pain, instability, and muscle imbalances, as well as identify limitations associated with sports and other physical activities.
Transcript
00:00:0400:00:08
This is Brent of the Brookbush
00:00:0400:00:08
Institute at the independent training
00:00:0800:00:11
spot, doing goniometric assessment. Now in this video we're going to do hip flexion
00:00:1100:00:14
range of motion, and then we're going to talk about some of the structures that
00:00:1400:00:16
would restrict hip flexion. I'm going to have my friend Melissa come out, she's
00:00:1600:00:21
going to help me demonstrate. Now before we get into actually the technique, we need
00:00:2100:00:25
to realize that hip flexion has a soft end feel okay, so that's the anterior
00:00:2500:00:30
thigh muscles approximating our bellies. Realize that a leaner individuals a firm
00:00:3000:00:36
end feel is not abnormal as you just get to the end of the posterior capsule, the
00:00:3600:00:40
end of the extensibility of the posterior capsule rather. Now before you
00:00:4000:00:44
guys jump all over me for the range of motion I have written up here, I have 110
00:00:4400:00:50
to 135 degrees. I tried to create a range of motion that encapsulates a lot of the
00:00:5000:00:54
range of motions I see out there from different research, you guys might have
00:00:5400:01:01
to do a little bit more research to find out where within this range you should
00:01:0100:01:04
be aiming for, for the specific population that you work with. I find
00:01:0400:01:09
that with the population I work with a fairly at least recreationally athletic
00:01:0900:01:15
if not professionally athletic individuals, 125 is probably a good range,
00:01:1500:01:21
give or take 5 degrees. Now as far as setup, we have a stabilization arm that's
00:01:2100:01:25
going to go through our mid axillary line, so all I did here was I laid a
00:01:2500:01:28
piece of tape down to kind of show you where that line is, from greater
00:01:2800:01:33
trochanter to the top of the iliac crest, through the armpit. Now the movement arm
00:01:3300:01:38
is going to go from the greater trochanter through the femoral condyle, or or just
00:01:3800:01:43
mid femur. The fulcrum is of course through the hip, but we're going to use the
00:01:4300:01:48
greater trochanter which is where these two lines meet, as kind of a reference
00:01:4800:01:53
point for where the hip rotates. The thing to be careful is Norkin and White
00:01:5300:01:57
kind of mention how they want this leg straight, the problem is is if this leg
00:01:5700:02:01
is flat on the table and the person that you're measuring has tightness and their
00:02:0100:02:06
hip flexors on the side you're not measuring, it'll pull their pelvis into
00:02:0600:02:12
an anterior pelvic tilt, which of course is then going to change the measurement you
00:02:1200:02:15
get at the hip. So you need to do a little bit of
00:02:1500:02:19
palpating here, make sure you grab the ASIS and kind of grab the posterior
00:02:1900:02:22
ilium, and make sure that they're not in that anterior pelvic tilt, they don't
00:02:2200:02:27
have an excessive lordosis. Make sure they're in neutral to start, and then
00:02:2700:02:31
when you're bringing them into hip flexion, you're going to keep their hand
00:02:3100:02:37
there, ASIS, posterior ilium, and only pressing the hip flexion until you get
00:02:3700:02:42
their pelvis starting to rotate, which means you've hit end of pelvic range. Now
00:02:4200:02:48
her lumbar spine is starting to flex, and she goes into a posterior pelvic tilt. So
00:02:4800:02:52
just to review here I'm going to palpate, I'm going to push, and right there is where
00:02:5200:02:56
I feel her starting to shift at her pelvis. I'm going to have her go ahead and
00:02:5600:03:02
hold this for me. Now I normally would not take this measurement by
00:03:0200:03:07
leaning over the top of Melissa, this is just to help you guys see where I put
00:03:0700:03:12
the goniometer right. So the stabilization arm is going to go right
00:03:1200:03:15
through that mid axillary line, you can see I set the fulcrum up on the greater
00:03:1500:03:21
trochanter. I then put my movement arm straight through the femoral condyle. All
00:03:2100:03:29
right mid femur, I'm going to take this off, and Melissa's got a hundred degrees of
00:03:2900:03:34
hip flexion, which if this was the only measurement I was going to take I'd say she
00:03:3400:03:37
was restricted. That's definitely not optimal for somebody as athletic as she
00:03:3700:03:42
is. Now I'm going to show you guys how I would actually do this test, forgive me
00:03:4200:03:47
for turning my back on you. So once again I'm going to make sure she's not in an
00:03:4700:03:51
anterior pelvic tilt, so I'm going to kind of palpate her pelvis here, make sure
00:03:5100:03:55
she's not in excessive lordosis, looks pretty good to me.
00:03:5500:04:01
All right I'm going to then once again palpate her pelvis, palpate her ASIS,
00:04:0100:04:06
bring her into as much hip flexion as I can until I start to feel her pelvis
00:04:0600:04:11
rotate. I'm then I'm going to have her hold, all right she can use a little bit of
00:04:1100:04:20
her muscular power here as well as this other hand, and then I'm going to have my
00:04:2000:04:24
stabilization arm along our mid axillary line. I'm going to set my fulcrum up with
00:04:2400:04:29
her greater trochanter, I got my movement arm set up going straight through her
00:04:2900:04:37
femoral condyle, and we can see once again I got a hundred degrees, so not
00:04:3700:04:44
so bad on my intra-tester reliability. So if she had a hundred degrees, now we have
00:04:4400:04:48
to start talking about what's restricting her motion, what exercises am
00:04:4800:04:52
I going to select for her home exercise program, and what am I going to do
00:04:5200:04:55
personally to help get her her range of motion back, Thanks Melissa.
00:04:5500:04:59
So let's talk about that, and let's break it down through the same paradigm I've
00:04:5900:05:03
been breaking down in all of these videos. What are the muscle , joint, fascial
00:05:0300:05:06
and nerve restrictions. So muscular restrictions, let's start with the
00:05:0600:05:10
posterior head of the adductor Magnus. If you remember the adductor Magnus has two
00:05:1000:05:15
heads, one of them actually extends and externally rotates the head, and it does
00:05:1500:05:19
have a propensity to get overactive in individuals. So I would definitely take a
00:05:1900:05:22
look at this posterior head of the adductor Magnus, and possibly release and
00:05:2200:05:27
stretch. Now some of you guys might be wondering why it isn't gluteus maximus up here,
00:05:2700:05:32
well we have both the research to back it up, and of course clinically we just
00:05:3200:05:38
don't see an overactive glute max, we don't see an adaptively shortened glute
00:05:3800:05:43
max. If you guys think about this I think you can just rationalize the fact that
00:05:4300:05:49
nobody has ever walked into your clinic, studio, gym, or a training facility and
00:05:4900:05:54
gone you know what my glutes are just too tight, it just doesn't happen
00:05:5400:05:57
right, we see a lot on the other side we see people who want tighter glutes, we
00:05:5700:05:59
don't really see glutes that are too tight, so they're probably not going to
00:05:5900:06:04
restrict your hip flexion range of motion. Your deep rotators can also
00:06:0400:06:08
restrict hip flexion if they get really really tight, and start binding down the
00:06:0800:06:13
posterior aspect of that joint. And then you guys will notice I have hip flexors
00:06:1300:06:17
written down here, well we can't forget that when we deal with joints we're also
00:06:1700:06:21
dealing with not just osteokinematics that's flexion and extension and
00:06:2100:06:24
external rotation, but we're also dealing with those arthokinematics that slide,
00:06:2400:06:34
glide, role. So hip flexors don't just flex the hip, they also glide the
00:06:3400:06:38
femoral head anteriorly, and unfortunately if my hip flexors get
00:06:3800:06:45
overactive and glide my femoral head anteriorly, that creates this impingement
00:06:4500:06:51
or this restriction where I can no longer get any further flexion, because
00:06:5100:06:56
while I'm flexing I should actually be going posterior with my femoral head. So
00:06:5600:06:59
if you guys get nothing out of release and stretch from these muscles,
00:06:5900:07:03
you might try releasing the hip flexors and seeing if that improves this range
00:07:0300:07:07
of motion. Now the joint and this is probably the biggest restriction to hip
00:07:0700:07:13
flexion, the posterior capsule of the hip does adaptively shorten in individuals
00:07:1300:07:17
with compensation patterns, and of course we have our lateral hip distraction and
00:07:1700:07:21
our posterior glide, you guys have that self-administered mobilization video I
00:07:2100:07:28
did, that will definitely be a big one for this particular restriction. You guys
00:07:2800:07:33
can also see I wrote down once again this is kind of a bonus, those lumbar
00:07:3300:07:37
spine, so the facet joints of the lumbar spine and the sacroiliac joint, if those
00:07:3700:07:42
are dysfunctional they can change muscular activity, they can change the
00:07:4200:07:47
tension within that fascial network, that lumbosacral fascial network which may
00:07:4700:07:53
also affect hip joint range of motion fascia. So once again I kind of just
00:07:5300:07:59
mentioned it here posterior hip and sacral fascia can definitely restrict hip
00:07:5900:08:03
flexion, and I might need to use my pin and stretch techniques, or maybe
00:08:0300:08:06
instrument assisted soft tissue mobilization, and I know there's a lot of
00:08:0600:08:10
other fascial techniques out there that you guys may try here. And of course if I
00:08:1000:08:17
pulled somebody into hip flexion, I do have to be aware that muscles, joints, and
00:08:1700:08:20
also nerves are involved in every range of motion. I'm not calling this a neuro-
00:08:2000:08:25
dynamic test by any means, but if somebody had a geared up sciatic nerve
00:08:2500:08:28
and I push them into hip flexion, and all of a sudden that reproduces their
00:08:2800:08:31
symptoms, I need to at least be aware that hip flexion does
00:08:3100:08:35
stretch the sciatic nerve around the back of the hip a little bit. It closes the
00:08:3500:08:40
piriformis and gemellus superior down on the sciatic nerve as well, and it's going to
00:08:4000:08:45
lengthen the lumbosacral plexus. If somebody has like some lumbar spine
00:08:4500:08:50
pathology, they have a nerve root adhesion, or they have some sort of
00:08:5000:08:56
radiculopathy, you may start to reproduce their symptoms. And of course we could go
00:08:5600:09:00
backwards through this grasp, maybe they started here, they stopped
00:09:0000:09:05
going into hip flexion and that's what caused the restriction. So I just gave
00:09:0500:09:08
you a whole lot of information, I hope what you can do with this is you have
00:09:0800:09:14
one more test that'll give you a few more ideas, to create even better
00:09:1400:09:19
programs, better exercise selection so that you get even better outcomes. I look
Related Videos
Hip Flexion Goniometry
Hip Extension Goniometry
Goniometry Hip Internal Rotation (in prone)
Knee Extension with Hip Flexion Goniometry (Hamstring Length Test)
Goniometry: Hip External Rotation at 90 Degrees of Hip Flexion (90/90 Hip ER)
Femoral Nerve Neurodynamic Tests
Lumbar Movement Assessment
Slump Test
Upper Body Movement Assessment
Straight Leg Raise Test and Well Leg Raise Test
Goniometry: Hip Internal Rotation at 90 Degree of Hip Flexion (90/90 Hip IR)
Ober's Test TFL Flexibility Assessment
Shoulder External Rotation Goniometry
Ely's Test (Rectus Femoris Flexibility Assessment)
Goniometry Hip External Rotation (in Prone)
