Knee Extension Goniometry
Knee Extension Goniometry is an assessment technique used to measure the degree of extension of the knee joint. This method can be used to assess the range of motion and flexibility of the patient's knee joint. Goniometry involves the use of a goniometer, which is a device used to measure the angle of the joint. The measurements obtained from Goniometry can be compared with normative data to establish if the patient's knee joint is functioning within normal ranges. Knee Extension G
Transcript
00:00:0600:00:09
This is Brent of the Brookbush Institute
00:00:0600:00:09
at the independent training spot in New
00:00:0900:00:12
York City, going over goniometric assessment. Now in this video we're going
00:00:1200:00:16
to go over knee extension goniometry which is something some of us are going
00:00:1600:00:19
to use a little bit, and some of us are going to use a whole lot, especially if
00:00:1900:00:22
you're in like an orthopedic rehab facility where you're doing a lot of
00:00:2200:00:27
knee replacements. Either way it's an important to have this assessment in
00:00:2700:00:30
your repertoire and have a good understanding of it, because just a
00:00:3000:00:34
slight loss of knee extension can lead to pretty significant losses and
00:00:3400:00:38
function, and definitely can lead to some knee pain. I'm going to have my friend
00:00:3800:00:42
Melissa come out, she's going to help me demonstrate this assessment. Now just
00:00:4200:00:47
like all of our other goniometric assessments we have a stabilization arm
00:00:4700:00:51
line and we have a movement arm line, and these lines are actually the same lines
00:00:5100:00:57
we've used for all of the other knee goniometry. So it's mid femur which
00:00:5700:01:02
is greater trochanter, through lateral condyle, and then joint line here, and
00:01:0200:01:05
then I just kept that line going straight through the fibular head and
00:01:0500:01:10
the lateral malleolus, because that would be the midpoint of her lower leg there.
00:01:1000:01:14
Now the fulcrum is going to be the joint line itself, the only caveat to this
00:01:1400:01:19
technique is if you look at the range of motion that is normal for knee extension,
00:01:1900:01:26
you'll see that this is 0 to 5 degrees. Now that's not five degrees this way
00:01:2600:01:32
five degrees, that's actually five degrees of what some would term hyper
00:01:3200:01:38
extension is normal right. So if I give her just a little bit of force this way
00:01:3800:01:43
you can actually see that her knee bows up, and that's a totally normal range of
00:01:4300:01:47
motion. Now to measure that I can't ask Melissa to hold hyper hold
00:01:4700:01:52
hyperextension go ahead and hold it, it just feels weird right. So she ends up
00:01:5200:01:56
contracting a lot of muscles to try to stabilize the joint, you probably end up
00:01:5600:01:59
with more neutral. The easiest way to measure this is have something
00:01:5900:02:04
underneath their ankles, I just grabbed a foam roll here because there's that's
00:02:0400:02:09
convenient, there's lots of foam rolls around here at ITS. So if i push her
00:02:0900:02:14
into her end range get that nice firm and feel i'm looking for, and she can
00:02:1400:02:17
kind of relax into that end feel, now as soon as I pull my hands up,
00:02:1700:02:24
she's where I need her to be for me to pull out my goniometer and take this
00:02:2400:02:29
measurement. All right so stability arm, fulcrum through the joint line, and then
00:02:2900:02:36
movement arm, and I got two degrees. Now of course doing goniometry like this is
00:02:3600:02:40
really terrible technique, so I'm going to turn my back to you guys, once again
00:02:4000:02:50
walk you through, walk you through this whole technique. So once again i got my
00:02:5000:02:54
stabilization arm, i got my movement arm, and I know where my fulcrum is going to
00:02:5400:03:00
be. I'm going to go ahead and throw her ankles up on this bolster or foam roll,
00:03:0000:03:06
I'm going to go ahead and push and make sure i feel that firm and feel. Alright
00:03:0600:03:12
once I know I have that firm and feel I'm going to go ahead and get down to eye
00:03:1200:03:18
line here, now I have to keep in mind that the mid femoral line is not going
00:03:1800:03:22
to be parallel to my table like it has been in other techniques we've used, it's
00:03:2200:03:26
going to kind of slope down towards her hip. So I got to be careful that I
00:03:2600:03:31
measure from that point, then as I go through my movement arm here, make sure
00:03:3100:03:39
my fulcrums lined up, I actually get two degrees of hyper extension or a negative
00:03:3900:03:48
2 degrees. Thank you Melissa. Now that's normal range of motion. But
00:03:4800:03:52
what would have happened if I got five degrees the other way, somebody with five
00:03:5200:03:59
degrees of less than optimal knee extension can't even lock their knee, and
00:03:5900:04:03
that's going to potentially lead to some dysfunction right, think of how hard
00:04:0300:04:07
your quads would have to work all the time even during standing, if you
00:04:0700:04:10
couldn't even lock your knee. So if I have somebody who has a knee extension
00:04:1000:04:14
restriction, I need to start thinking of all of those tissues that could restrict
00:04:1400:04:20
that range of motion, and what techniques could I possibly use to improve that
00:04:2000:04:24
range of motion. So starting with my muscles, I know that all of my flexors
00:04:2400:04:29
are going to contribute to a lack of knee extension. So my hamstrings of
00:04:2900:04:33
course and we know biceps femoris has a propensity to get over active in a lot
00:04:3300:04:38
of individuals, my gastrocnemius, probably my lateral gastroc more specifically, and my
00:04:3800:04:42
popliteus which has a propensity to get overactive and develop trigger points,
00:04:4200:04:46
are all muscles that maybe I could release, maybe I could lengthen with some
00:04:4600:04:54
stretching techniques. Then we move on to joint here and we see a whole lot of the
00:04:5400:04:59
joint itself, the the capsule the ligaments that are holding my femur to
00:04:5900:05:03
my tibia, a lot of them restrict extension. My popliteal ligaments, my
00:05:0300:05:08
collateral ligaments, that's lateral and medial, my cruciate ligaments right
00:05:0800:05:12
that's anterior and posterior. From the perspective of this guys, think about all
00:05:1200:05:17
those individuals who go in for anterior cruciate ligament repairs or lateral
00:05:1700:05:21
collateral ligament repairs like do you think they're going to have a limit of
00:05:2100:05:25
knee extension? Probably. So now the question is how do we affect the joint
00:05:2500:05:30
itself, when I start thinking about my arthrokinematics, start thinking about
00:05:3000:05:38
the fact that the tibia right, my lower leg, has to glide anteriorly to and to
00:05:3800:05:43
make sure i get to terminal extension. If I don't have that that gliding
00:05:4300:05:47
anteriorly of the tibia, then I can hit end rage extension. A lot of the
00:05:4700:05:53
individuals who end up with surgical repairs here, they lose that ability,
00:05:5300:05:55
and then I have to start thinking about my techniques again after I get through
00:05:5500:06:02
my soft tissue stuff. Maybe I'm going to do my femur on tibia anterior to
00:06:0200:06:07
posterior mobilizations, or if they can flip them over into prone and I could
00:06:0700:06:12
do my tibia on femur posterior to anterior mobilizations. And if I want to
00:06:1200:06:18
get really fancy I can focus maybe more on the lateral compartment of the knee
00:06:1800:06:24
joint, to make sure that I'm not stuck in tibial external rotation. I hope you guys
00:06:2400:06:32
caught all that. Don't forget the patella femoral joint and the proximal tibia tibia,
00:06:3200:06:38
sorry that should say tibiofibular joint here guys. Let me rewrite that all
00:06:3800:06:44
right. So your proximal tibia fibula joint and your patella femoral joint
00:06:4400:06:52
lock into all those soft tissues right, and if they they attached all these soft
00:06:5200:06:57
tissues they can create overactivity, if their dysfunctional, so my proximal
00:06:5700:07:02
fibula being stuck posteriorly, might need to be mobilized anteriorly. My patella
00:07:0200:07:06
femoral of course we could go on for hours about patella femoral alignment,
00:07:0600:07:13
and and how it moves and glides and and tilts. Make sure you get some of those
00:07:1300:07:18
techniques in your repertoire. Fascia so all of those who are using fascial
00:07:1800:07:24
techniques. The posterior fascia lata of course that fascia over my hamstrings, my
00:07:2400:07:28
posterior crural fascia, the fascia over my calf. And my popliteal fascia, actually
00:07:2800:07:35
the fascia in the back of my knee can all restrict terminal knee extension here.
00:07:3500:07:40
And if you're using assisted instrument, assisted soft tissue mobilization, or
00:07:4000:07:43
your pin and stretch techniques, or myofascial release techniques, these are
00:07:4300:07:47
all areas to work on, but don't forget the lateral fascia lata on the iliotibial
00:07:4700:07:53
band. There is kind of a cross over there guys where the iliotibial band will
00:07:5300:08:01
assist in some flexion right, and if it's bound down, if it's tight, it
00:08:0100:08:07
will resist extension right. I think that turnover happens at about 30 degrees, but
00:08:0700:08:10
it's definitely worth investigating with your fascial techniques if you're having
00:08:1000:08:14
a hard time getting somebody back to normal knee extension. Now of course if i
00:08:1400:08:21
had pushed on Melissa's knee and i got any sort of nerve symptom, i might think
00:08:2100:08:25
common fibular or tibial nerves. Now goniometric assessments aren't great ways
00:08:2500:08:33
of assessing nerve neurodynamics, but if I started thinking okay wait a second
00:08:3300:08:36
she's feeling something here, it seems to be kind of one of those nerve symptoms, I
00:08:3600:08:39
need to do my neurodynamic tests, and I'm going to probably start
00:08:3900:08:47
differentiating here. So guys there's a huge graph for a very small range of
00:08:4700:08:52
motion that happens to be very important. I hope you guys will start using this
00:08:5200:08:55
knee extension goniometry, at least experimenting with it on your colleagues,
00:08:5500:09:01
see who has optimal and who doesn't, and start asking them about their history of
00:09:0100:09:05
maybe knee pain, knee dysfunction, knee surgery, and see if you guys can start
00:09:0500:09:09
putting some pieces together. And then of course with all of the graphs that are put
00:09:0900:09:14
up here guys it's not to intimidate, it's not to make this look an overwhelming
00:09:1400:09:18
amount of information, it's just to give you as many possibilities as you can
00:09:1800:09:23
think of, as many tissues as I can think of to address, so that when somebody
00:09:2300:09:29
comes in you have lots of tools in your toolbox, a huge arsenal to use to get
00:09:2900:09:32
them back to optimal motion. I look forward to hearing about you guys's
