Knee Flexion Goniometry
Knee Flexion Goniometry is a form of clinical assessment used to measure the range of motion in the knee. It is performed using a goniometer, which is a device used to measure angles. During the assessment, an examiner records the angle between the thigh and shin at several different points during a knee flexion and extension range of motion. The results from goniometry are then used to diagnose injuries, follow recovery after an injury, or to monitor progress in a rehabilitation program
Transcript
00:00:0600:00:10
This is Brent of the Brookbush Institute
00:00:0600:00:10
at the independent training spot in New
00:00:1000:00:13
York City. Today we are doing goniometric assessments, so we're looking at
00:00:1300:00:17
the range of motion of the knee and knee flexion. I'm going to have my friend Melissa
00:00:1700:00:20
come out, she's gonna help me demonstrate this test, and then once I've showed you
00:00:2000:00:24
how to do this test we'll talk about what could possibly restrict this range of
00:00:2400:00:29
motion. So first things first I need my two lines and my pivot points. So i had a
00:00:2900:00:33
mid femoral line that i'm going to use, a line that goes straight through my
00:00:3300:00:38
fibula from fibular head to lateral malleolus, and my pivot point is actually
00:00:3800:00:44
the lateral condyle of my femur. Now the way we're going to do knee flexion is we
00:00:4400:00:49
have to do it in a little hip flexion so that this test doesn't become biased
00:00:4900:00:54
towards just one muscle, which we'll talk about in a second with the Ely's test. So
00:00:5400:01:00
real easy guys all you have to do is basically sandwich their leg together, a
00:01:0000:01:03
normal end feel actually on this one a little different than some of the other
00:01:0300:01:07
tests we did, is actually soft it should be a soft end feel, should be the
00:01:0700:01:15
approximation of her hamstrings to her calves, a squishy feeling. Alright then i
00:01:1500:01:23
would go ahead and put my stabilization arm through the femur, femoral head is my
00:01:2300:01:28
pivot point, and my movement arm goes through the fibula, and we have a hundred
00:01:2800:01:35
and thirty-seven degrees of the flexion, which is normal. Alright so let me show
00:01:3500:01:37
you how I would actually do that test guys, because obviously I wouldn't just
00:01:3700:01:44
lean over somebody and squish them from the other side. So
00:01:4400:01:50
I would go ahead and start here, make sure I have a good position so I can
00:01:5000:01:53
look straight down on her knee and make sure it's in alignment. Then take her into
00:01:5300:01:56
hip flexion, make sure I don't pull her into internal rotation or external rotation,
00:01:5600:02:01
I'm not pushing her into adduction as I do this. I just want nice pure knee
00:02:0100:02:07
flexion, make sure I get a good end feel nice and soft, alright and then once I
00:02:0700:02:11
have it there I can use her foot to plant if I want, or maybe with some
00:02:1100:02:16
people you might have to hold it in place. I'm going to kneel down so that
00:02:1600:02:21
I'm eye level with my goniometer and I can get as accurate a read as possible.
00:02:2100:02:27
Make sure I line up those lines as well as I possibly can too. All right once
00:02:2700:02:31
again pivot points femoral head, movement arm straight through the greater
00:02:3100:02:34
trochanter, or I'm sorry stabilization arms straight through the greater
00:02:3400:02:38
trochanter, move then arms straight through the fibula right down to that
00:02:3800:02:45
lateral malleolus, and I actually got a bit more range of motion this time
00:02:4500:02:50
about 145 degrees, and i'll have to watch the video to see how I messed that up
00:02:5000:02:57
when I was on the other side, thank you Melissa. So fairly easy range of motion
00:02:5700:03:04
to test with with knee flexion in hip flexion. The question is now what does
00:03:0400:03:11
that show us restriction of? Well to tell you the truth muscular restriction is
00:03:1100:03:16
not as common on this test, and you'll see the first muscle i have written up
00:03:1600:03:19
here is the articularis genu which some of you may not have even heard of.
00:03:1900:03:26
The articularis genu plays a role at the knee to help draw the anterior
00:03:2600:03:32
capsule out of the way so it doesn't get pinched as we go into knee extension. If
00:03:3200:03:36
it gets tight however it can tighten that anterior capsule and restrict us
00:03:3600:03:41
from going all the way into knee flexion. Then I list all the vastus muscles,
00:03:4100:03:45
because the vastus muscles don't really have a propensity to get tight in
00:03:4500:03:49
individuals, and then you'll notice I list the rectus femoris because for
00:03:4900:03:53
the rectus femoris to restrict that position, would be highly unlikely
00:03:5300:03:58
considering we're shortening it at the hip. So once again guys
00:03:5800:04:05
this particular range of motion muscular restriction not all that common, to be
00:04:0500:04:08
quite honest if I had to guess the most common reason why knee flexion gets
00:04:0800:04:13
restricted, it's going to be this fancy word for swelling right, a fusion. So you
00:04:1300:04:16
get these people who kind of have chronic dysfunction at the knee and they
00:04:1600:04:21
start to get the swelling, well that swelling fills up the joint capsule like
00:04:2100:04:26
a balloon. Once you take up all of the stretch in the anterior capsule of the
00:04:2600:04:30
knee you can't push it into flexion. In fact people sometimes feel it, they
00:04:3000:04:33
almost feel like their knee is going to burst when you start pushing it into
00:04:3300:04:39
that position. Of course for a fusion we might need to use ice, we might need to
00:04:3900:04:45
use wraps, we might need just just some time, or if it's chronic we may need to
00:04:4500:04:49
start looking towards referring out and finding out what else is going on inside
00:04:4900:04:53
of that knee that keeps bringing this effusion back. After a fusion we have
00:04:5300:04:59
anterior capsule tightness somewhat common, don't forget about your patella
00:04:5900:05:05
femoral joint and joint mechanics. So something like patella Alta where you
00:05:0500:05:10
have that rise of the patella because of a super tight rectus femoris, or super
00:05:1000:05:15
tight vastus lateralis for that matter might be affecting the flexion, so that's
00:05:1500:05:19
not necessarily the tibial femoral joint with the patella getting in the way, and
00:05:1900:05:23
you might need to release and stretch your rectus femoris and vastus lateralis.
00:05:2300:05:28
Your proximal tib/fib joint guys I put this up here not because it necessarily
00:05:2800:05:36
restricts flexion as much as it can be a source of pain that you find it when you
00:05:3600:05:41
squish somebody into flexion, as it gets somebody try that, the soft tissues
00:05:4100:05:46
trying to push that proximal fibular head anteriorly and it does not want to
00:05:4600:05:52
go. In fact this leads to the only nerve finding that I sometimes get in this
00:05:5200:05:57
test which is sometimes you put somebody into flexion as far as you can, it
00:05:5700:06:04
pinches all the soft tissues, shoves the proximal fibular head forward and
00:06:0400:06:08
pinches on that common fibular nerve. Alright so now you know you have a
00:06:0800:06:11
little bit of dysfunction at the knee, and the
00:06:1100:06:17
proximal tib/fib joint. And of course fascial restrictions are my anterior fascia
00:06:1700:06:22
lata. So all those pin and stretch, instrument assisted soft tissue
00:06:2200:06:28
mobilization techniques we can do to help relieve any restriction we might
00:06:2800:06:33
have. Now I do have to bring Melissa out here for one more knee test that I know
00:06:3300:06:40
you all have seen. I'm going to have you lay on your belly this time. In another video I
00:06:4000:06:45
actually already discussed this, we talked about the Eli test. All right and
00:06:4500:06:51
then the Eli test I go ahead and palpate, all right the tops of her PSIS alright, and
00:06:5100:06:58
I'm going to go ahead and push her knee until I feel her getting pulled into an
00:06:5800:07:01
anterior pelvic tilt, which would push her PSIS that way, and I would feel it
00:07:0100:07:08
in my fingers. Problem with this test as far as knee flexion goniometry is it
00:07:0800:07:14
basically biases this test to almost a single muscle once you get past
00:07:1400:07:18
a certain amount of degrees. I'm sure we could use this test for some other, to
00:07:1800:07:23
implicate some other structures but right here what i'm doing right now, this
00:07:2300:07:27
is all rectus femoris guys. So once I pull her all the way back in a neutral
00:07:2700:07:31
hip extension, I have her rectus femoris lengthened up at the hip, and this is
00:07:3100:07:37
just lengthening it even further. Great test, great test that you can use within
00:07:3700:07:43
your assessments if you suspect rectus femoris tightness. But if you're just
00:07:4300:07:46
looking for knee kinematics and you're just looking at what is going on to
00:07:4600:07:52
restrict knee motion, I would once again have somebody flip over
00:07:5300:07:58
and go right back to my knee flexion goniometry this way. I hope that
00:07:5800:08:02
makes sense, i hope i have given you guys a ton of things to think about as far as
00:08:0200:08:10
improving this range of motion. I did forget to mention one thing, we didn't
00:08:1000:08:13
talk about ligaments at the knee. The ligaments at the knee guys and there is a
00:08:1300:08:17
reason i didn't mention them, the ligaments of the knee almost all are
00:08:1700:08:21
biased towards extension, I know some of you guys who've seen post-surgical
00:08:2100:08:28
ligament repairs have seen a lot of restriction in flexion, and that's just
00:08:2800:08:32
because a lot of the ligaments at the knee actually stayed taught throughout
00:08:3200:08:40
the entirety of knee flexion or knee extension. So if you have an ACL or PCL
00:08:4000:08:45
reconstruction, let's say you might have a limit in overall range of motion at
00:08:4500:08:49
this knee in both extension and flexion, i think the thing to remember though is
00:08:4900:08:52
if we're not talking about a reconstruction we're not talking about a
00:08:5200:08:59
ligament damage, this doesn't implicate any particular ligament. Knee extension
00:08:5900:09:03
does, knee flexion does not. I hope I gave you guys a ton of information to look at,
00:09:0300:09:07
a ton of techniques to think about to improve this range of motion. I hope I've
00:09:0700:09:12
helped your assessments go a little deeper so that your exercise selection
00:09:1200:09:14
is that much more sophisticated. I'll look forward to hearing from you guys
