Knee Joint Anterior to Posterior (Femur on Tibia) Manual Mobilization

Knee Joint Anterior to Posterior (Femur on Tibia) Manual Mobilization is a hands-on physical therapy technique used to enhance movement of the knee joint. This technique applies gentle yet firm pressure to the anterior and posterior aspects of the knee joint. This mobilization releases restrictions in the knee and surrounding soft tissues which can lead to improved range of motion, strength, and functional mobility. Patients may experience some mild discomfort during the procedure, but it is important to note that this

Transcript

00:00:0500:00:07
This is Brent of the Brookbush Institute, and in this
00:00:0500:00:07
video we're going to go over a joint
00:00:0700:00:11
based manual therapy technique. If you're watching this video I'm assuming you're
00:00:1100:00:14
watching it for educational purposes, and that you are a licensed professional
00:00:1400:00:20
with joint based techniques within your scope. That means osteopath's, chiropractors,
00:00:2000:00:24
physical therapists, you're probably all in the clear. Physical therapy assistants,
00:00:2400:00:28
athletic trainers, massage therapists, you need to check with your governing body
00:00:2800:00:32
in your state or region, to see whether this is within your scope of practice.
00:00:3200:00:36
Personal trainers this is definitely not within your scope of practice. Of course
00:00:3600:00:41
all professions could use this video for purely educational purposes, to help with
00:00:4100:00:47
learning biomechanics, anatomy and of course palpation. In this video we're
00:00:4700:00:51
going to do posterior to anterior tibia on femur, or rather let's do
00:00:5100:00:54
anterior to posterior femur on tibia mobilization since they're the same
00:00:5400:01:00
relative arthrokinematic motion, but the latter allows us to get in good
00:01:0000:01:04
body position making it easy for us to perform the technique. I'm going to have
00:01:0400:01:07
my friend Melissa come out, she's going to help me demonstrate this technique.
00:01:0700:01:10
Now if I'm doing this technique on Melissa I've already done some sort of
00:01:1000:01:15
passory excessive motion exam on her knee, and I've assessed her as having artho-
00:01:1500:01:20
kinematic stiffness right. We don't want to be using mobilizations on
00:01:2000:01:24
hypermobile joints, that's not going to make anybody feel better. The other joint
00:01:2400:01:28
action we need to check for because of the way this technique is set up, is if
00:01:2800:01:34
Melissa had beyond normal extension of the knee that's beyond five degrees of
00:01:3400:01:38
hyperextension, I also wouldn't use this technique because of the way I'm pushing
00:01:3800:01:42
down this way, I could end up making hyperextension,
00:01:4200:01:47
hypermobility worse, which is also not going to make anybody feel any better.
00:01:4700:01:54
Now traditionally this technique is used to increase extension of the knee so
00:01:5400:01:59
somebody who lacks full range of extension, and this is all based on
00:01:5900:02:06
concave on convex rules that's glide same as roll. However I think research is
00:02:0600:02:10
kind of pointed to the fact that those rules are not completely reliable when
00:02:1000:02:14
it comes to the knee. Now what does that mean, it probably means that mobilization
00:02:1400:02:18
in the either direction could potentially be effective for
00:02:1800:02:24
either extension or flexion, which I know creates some grey area but here's what
00:02:2400:02:29
you're going to do. This is the technique I fall back on most often because I find
00:02:2900:02:35
it most effective, most often. But if you wanted to try mobilization in the other
00:02:3500:02:40
direction the only thing I would ask is that you assess, do your intervention, and
00:02:4000:02:46
reassess; and then if you're going to try the other technique, do that and reassess
00:02:4600:02:50
again. You want to try to determine which technique, which direction of glide is
00:02:5000:02:54
most effective, write that down and continue to use that with your patient
00:02:5400:02:58
or client. Now I'm going to have Melissa go ahead and put her leg down so that
00:02:5800:03:03
you guys can see what I'm doing to Melissa's knee here, what my hand position
00:03:0300:03:09
is, what I'm palpating, and how I set this up. So we wanted to do a posterior to
00:03:0900:03:15
anterior glide on the tibia, or the tibia on the femur, and rather we turned it
00:03:1500:03:18
around. So we're going to do anterior to posterior on the femur so that we can
00:03:1800:03:23
push, because pushing is a lot easier than pulling. I don't want to manhandle
00:03:2300:03:27
and wear my hands out, or wear my body out trying to do this mobilization. In
00:03:2700:03:33
order to get myself a little space anterior to posterior I had to elevate
00:03:3300:03:36
Melissa's leg just a little bit, so that's where this half foam roll comes
00:03:3600:03:41
in, and guys I find half foam rolls to be the best thing for this technique; and
00:03:4100:03:45
notice this isn't one of those super hard like premium foam rolls, this is
00:03:4500:03:52
kind of a soft dish foam roll. So it's firm, but not so firm that it's
00:03:5200:03:58
mean on Melissa's calf. Alright you could use a pillow, like one of these round pillows
00:03:5800:04:01
that's under Melissa's head, just realize that if you use one of those round
00:04:0100:04:05
pillows you're going to have to push all the way through the pillow softness,
00:04:0500:04:12
before you're going to be palpating any sort of arthrokinematic motion. Now like
00:04:1200:04:18
all of our techniques for mobilizations and soft tissue techniques and sometimes
00:04:1800:04:24
even exercise, the more Anatomy you know the better. With the knee maybe you want
00:04:2400:04:28
to start by finding the patella, the kneecaps kind of easy to find.
00:04:2800:04:33
So I can start outlining the borders of her patella, I can find her patellar
00:04:3300:04:37
tendon or patellar ligament depending on what you want to particularly call it.
00:04:3700:04:43
I'll find her tibial tuberosity right here, I can find the top of her patella
00:04:4300:04:49
and then maybe I want to let my hand sink down medial and lateral, so that I
00:04:4900:04:54
can feel through her soft tissue and find those femoral condyles, which should
00:04:5400:05:01
feel like roundish bumps kind of on the superior half of where her patella was
00:05:0100:05:06
right -so the end of the femur. If I go lower than that I should be able to feel
00:05:0600:05:10
the tibia which is going to feel a little bit more ridgey, alright so your
00:05:1000:05:14
femoral condyles are nice and round, your tibia kind of comes up and then hits a
00:05:1400:05:19
plateau. Now if you visualize that you should be able to come to the end of
00:05:1900:05:26
those round bumps and the end of all those ridges, and find a depression
00:05:2600:05:32
that's a line, that's the joint line, this is going to be an important part of this
00:05:3200:05:37
technique, the thing that we really want to try to to palpate. So see if you can
00:05:3700:05:43
feel through that soft tissue in here nicely, don't jab your fingers into your
00:05:4300:05:48
your partner's clients or patients knee, that's not going to feel good, but gently
00:05:4800:05:51
kind of try to find that joint line. If you want you could have your patient
00:05:5100:05:55
like flex their knee a little bit and then straighten it, flex it and straighten it,
00:05:5500:05:57
flex it and straighten it, so that you can kind of find where that joint line
00:05:5700:06:02
is, there we go got it. Alright once I found her joint line I'm just going to
00:06:0200:06:06
set my hands down around her patella, because the last thing I want to do is
00:06:0600:06:10
this, if you guys know Clark's sign or Clark's test, or the patellar compression
00:06:1000:06:15
test, if you've ever done it, it just kind of hurts everybody, it's not a real great
00:06:1500:06:19
test. It's supposed to be a test for knee pain, but you push down on somebody's
00:06:1900:06:23
patella to have them extended it just freaking hurts so don't do that. Instead
00:06:2300:06:27
take your web spaces and just kind of put it around the patella, put your index
00:06:2700:06:32
fingers and your thumbs down over the joint line. Now you're going to apply
00:06:3200:06:40
pressure using the arm that's over the femur with the palm of your hand, and you
00:06:4000:06:44
really want to use a lot of the surface of your hand. I've
00:06:4400:06:47
explained this in some of your other in in some of our other videos you don't
00:06:4700:06:50
want to use fingertips to do mobilizations if you don't have to,
00:06:5000:06:56
because they're going to feel really pointy and even your webspace with it's
00:06:5600:07:02
very narrow surface area, can feel like a chisel into somebody's knee, it just
00:07:0200:07:07
doesn't feel good. Alright so hands down right around the
00:07:0700:07:11
patella just like so, we're going to put index fingers on the joint line, thumbs on
00:07:1100:07:18
the joint line, and I'm getting ready to push down here. Now is where we start
00:07:1800:07:23
thinking about okay do I have any contraindications to think about. Well
00:07:2300:07:28
obviously if I started pressing in, if I started in like this and Melissa
00:07:2800:07:33
immediately starts complaining of pain, that would be a bad thing. We might want
00:07:3300:07:37
to back off and find another technique, and of course if you have somebody who's
00:07:3700:07:41
come in after acute knee injury you got to start thinking about did they
00:07:4100:07:48
potentially tear any of the ligaments of the knee, even like just mild mild tears
00:07:4800:07:52
can cause a pretty significant amount of pain, and maybe you have to go back and
00:07:5200:07:57
do your special tests. Of course you could press down and impinge on
00:07:5700:08:01
nerves or impinge on some trigger points, generally those are easy to get around
00:08:0100:08:08
by just moving your hands a tiny bit. Remember trigger points aren't generally
00:08:0800:08:14
very large things and nerves are definitely not very large things right,
00:08:1400:08:17
they're very narrow, we're talking like millimeters. So usually you can just kind
00:08:1700:08:20
of reposition your hands and somebody like ahh,
00:08:2000:08:25
and I'm like well what happened, you're like right above my knee it hurt, okay
00:08:2500:08:28
let me let me move my hand around a little bit.
00:08:2800:08:35
Notice that the table is low enough so that I can get my chest over this
00:08:3500:08:38
technique, because once again I don't want to muscle this technique. Melissa
00:08:3800:08:44
has super strong legs and the knee is a nice big joint, so I want to be able to
00:08:4400:08:50
use my upper body mass to create the force, and now I'm just going to go back
00:08:5000:08:54
to whatever protocol it is that I use. Now I've mentioned in other videos I
00:08:5400:08:57
happen to be in certified orthopedic manual
00:08:5700:09:04
therapists through through Maitland, so I use the 50% grade three and four right.
00:09:0400:09:09
So grade three's would be larger amplitude at fifty percent, grade four
00:09:0900:09:12
would be smaller amplitude at fifty percent -now that's fifty percent between
00:09:1200:09:16
first resistance barrier and end of arthrokinematic range, and you're going
00:09:1600:09:20
to keep oscillating at one to two oscillations per second until you feel a
00:09:2000:09:26
decrease in joint stiffness. Now if you use another protocol that's fine, I think
00:09:2600:09:32
there's a lot of protocols out there, the thing they all have in common is finding
00:09:3200:09:36
first resistance barrier, so that's first resistance barrier for Melissa, and I'm
00:09:3600:09:40
palpating the joint line right now. So I should be able to really easily find
00:09:4000:09:45
where the end of arthokinematic range is, that is no matter how much
00:09:4500:09:52
harder I push right now, I'm not getting any more motion in glide, that's femur on
00:09:5200:09:57
tibia glide, no matter how much harder I push I'm not getting any more motion. So
00:09:5700:10:02
I know where the beginning is, I know where the end is. Most protocols have you
00:10:0200:10:09
mobilized somewhere in between whatever protocol you use, just make sure you go
00:10:0900:10:11
through with it. Alright make sure you do it from
00:10:1100:10:18
beginning to end, that you don't half-ass it per se right, that you actually do the
00:10:1800:10:24
protocol, give the technique a fair chance, so that when you go to reassess
00:10:2400:10:30
you know whether it was an effective technique, and it wasn't just bad form on
00:10:3000:10:35
your part that didn't get you the result that you were looking for. How does that
00:10:3500:10:41
feel? A little weird, it does feel a little weird to be pushed pushed into
00:10:4100:10:47
this direction right, like this is this is end range knee extension. Melissa does
00:10:4700:10:51
have a little bit of stiffness here though, so I'm going to see how it makes
00:10:5100:10:57
you feel upon reassessment. I'm thinking she'll feel a little bit better. Alright
00:10:5700:11:00
guys so I want to set that up for you one more time before we go to the close
00:11:0000:11:05
up recap. Notice that the table is low enough that when I palpate her knee I
00:11:0500:11:08
have to lean over just a little bit, that its
00:11:0800:11:13
purposeful so that I can use my upper body mass to create the force, and I'm
00:11:1300:11:18
not manhandling and using my upper body strength or the strength of my hand to
00:11:1800:11:21
get this mobilization done, that's not going to work.
00:11:2100:11:25
I then am going to find her patella, and I'm going to put my hands down around
00:11:2500:11:30
her patella, no Clark sign or Clark's test, like it's a bad idea it
00:11:3000:11:36
hurt so bad. Alright once I have my hands down around her patella I think
00:11:3600:11:41
it's good practice to find the joint line. It's going to make it so much
00:11:4100:11:46
easier to find your first resistance barrier and end arthrokinematic
00:11:4600:11:51
range. I'm not sure why it's not more common to teach palpation of the joint
00:11:5100:11:55
line for this technique when your hands are right here. You're then going to
00:11:5500:12:00
apply force through the arm on the femur right, this hand you can use to kind of
00:12:0000:12:04
make sure that the tibia doesn't rotate if you'd like, or to stabilize the tibia
00:12:0400:12:10
or you know, you could even adjust as you're going the foam roll in case like
00:12:1000:12:15
I press down and I press the foam roll right into a gastroc or a soleus trigger
00:12:1500:12:19
point, obviously I would move that. This hand essentially though it's just going
00:12:1900:12:24
to be there to stabilize, while this one applies the force. I'm going to find my
00:12:2400:12:30
first resistance barrier, find the end of arthrokinmatic range, back off to 50%, and
00:12:3000:12:38
if I was doing a grade 4 it would be a very small amplitude oscillation, one to
00:12:3800:12:42
two oscillations per second, and notice I'm just rocking my upper body, you guys
00:12:4200:12:46
don't see me doing this with my arms right, no pumping, not pumping her knee, I'm
00:12:4600:12:51
just rocking with my arms putting weight this way right so it's all coming down
00:12:5100:12:58
through this arm, with a nice large surface area created by the entirety of
00:12:5800:13:03
my palm, not my web space. Stay tuned for the close-up recap. So for a close-up
00:13:0300:13:08
recap guys once again it always helps to know your Anatomy. So we have Melissa's
00:13:0800:13:15
patella here, and then if I just kind of sink my hands down I can start feeling
00:13:1500:13:19
well there's the fibular head right there. If I follow the fibular head this
00:13:1900:13:24
nice rounded bony landmark here, I actually
00:13:2400:13:31
feel like a little guitar string right here, that's actually her LCL which leads
00:13:3100:13:36
right into her joint line which is exactly where I want my thumbs to be. Now
00:13:3600:13:39
notice how I've positioned my hands here guys I got both my thumb's over the
00:13:3900:13:46
joint line so that I can feel glide, but my hands themselves are around her
00:13:4600:13:50
patella; again we don't want to mimic Clark sign and give her patellar pain
00:13:5000:13:57
for no reason. Now as soon as I kind of get myself in good position, I got her
00:13:5700:14:02
leg nice and stable with my left hand here, with my right hand I'm just going
00:14:0200:14:07
to go ahead and apply a little bit of force until I start to feel some glide,
00:14:0700:14:12
and then I'm going to keep applying force until I feel the end of arthro-
00:14:1200:14:18
kinematic range of motion, I then can back off 50% and I can start doing my
00:14:1800:14:24
oscillations. Remember guys to keep your bodyweight over your hands, you're using
00:14:2400:14:29
the weight of your upper body mass, your torso to create these oscillations.
00:14:2900:14:34
You're not muscling it with your hands, or even trying to muscle it with your
00:14:3400:14:40
arms, it should be a nice sway that's applying all this force; and of course
00:14:4000:14:44
once I finished my mobilizations I could then go ahead and reassess. So there you
00:14:4400:14:47
have it assess, address, reassess. Make sure that
00:14:4700:14:52
every time you choose a joint based manual therapy technique it is based on
00:14:5200:14:55
an assessment, and that you return to that assessment after you've finished
00:14:5500:15:00
the intervention to see if it was effective for the individual, the patient
00:15:0000:15:04
or clients that you had in front of you. Ensure that you continue to learn your
00:15:0400:15:09
Anatomy because your Anatomy is going to help you with your hand placement, with
00:15:0900:15:15
understanding what a joint can do, with understanding what you may gain from
00:15:1500:15:21
this particular technique. And of course practice, you have to practice these
00:15:2100:15:25
techniques, hopefully not for the first time on a patient or client who just
00:15:2500:15:30
walked in the door. If you can, find a more senior instructor or a mentor to
00:15:3000:15:36
give you some really good hands-on instruction. Use your peers for some good
00:15:3600:15:44
feedback, and of course always look for live education to help with your manual
00:15:4400:15:49
therapy techniques. I know these videos make education very convenient, but there
00:15:4900:15:54
is no substitute for learning manual therapy in a live setting. I look
00:15:5400:15:58
forward to talking to you guys again soon.
