Proximal Tibiofibular Joint Posterior to Anterior Manual Mobilization

This technique encourages improved joint gliding and range of motion pronation and supination for the proximal tibiofibular joint (between the tibia and fibula). It is performed posterior to anterior, with the therapist using their hands to impart a slow, controlled mobilization movement on the distal fibula and tibia. This has been shown to reduce pain and improve external and internal tibial rotation range of motion in those with proximal tibiofibular joint

Transcript

00:00:0500:00:07
This is Brent of the Brookbush Institute, and in
00:00:0500:00:07
this video we're going to go over a
00:00:0700:00:11
joint based manual therapy technique. If you're watching this video I'm assuming
00:00:1100:00:14
you're watching it for educational purposes, and that you are a licensed
00:00:1400:00:19
professional with joint based techniques within your scope; that means osteopath's,
00:00:1900:00:23
chiropractors, physical therapists, you're probably all in the clear. Physical
00:00:2300:00:27
therapy assistants athletic trainers massage therapists you need to check
00:00:2700:00:30
with your governing body in your state or region to see whether this is within
00:00:3000:00:35
your scope of practice. Personal trainers this is definitely not within your scope
00:00:3500:00:39
of practice. Of course all professions could use this video for purely
00:00:3900:00:45
educational purposes to help with learning biomechanics, anatomy and of
00:00:4500:00:49
course palpation. In this video we're going over posterior to anterior fibula
00:00:4900:00:53
and tibia mobilization. Now this is proximal tibiofibular joint. I'm going to
00:00:5300:00:56
have my friend Melissa come out she's going to help me demonstrate. Now this is
00:00:5600:01:00
one of those techniques that you'll probably use rarely, but when somebody
00:01:0000:01:05
needs this technique it often results in a big change in their symptoms, or a big
00:01:0500:01:09
change in their dysfunction, so keep this in your back pocket. We can kind of see
00:01:0900:01:14
how this joint is really in the middle of a bunch of stuff going on. Research
00:01:1400:01:20
kind of shows that hyper or hypo mobility may be related to knee pain, but
00:01:2000:01:26
if we use just a little bit of knowledge of our anatomy, we could see how perhaps
00:01:2600:01:32
dysfunction of this joint could lead to lateral knee pain from the LCL being
00:01:3200:01:37
stressed right, the LCL attaches to the fibular head. We could see how
00:01:3700:01:43
overactivity of the TFL, vastus lateralis and biceps femoris might be related to
00:01:4300:01:49
dysfunction of this joint. So like I said keep this one in your back pocket, there
00:01:4900:01:52
is going to come a point where you're going to need this technique. Now
00:01:5200:01:57
assessment of this technique is going to have to rely on passive accessory motion
00:01:5700:02:03
exam, and I know there's been some consideration of how reliable that those
00:02:0300:02:09
those exams are, but we really don't have a better alternative. In order to do
00:02:0900:02:14
these passive accessory motion exams as well as in order to do this technique, we
00:02:1400:02:18
have to be able to palpate this joint and feel what's going on. So to
00:02:1800:02:24
find the fibular head my suggestion is find your patella. Yeah I think most
00:02:2400:02:28
people can find their patella, their kneecap. Most people know where their
00:02:2800:02:33
kneecap is, if you follow that down right you kind of feel the patellar tendon, and
00:02:3300:02:37
if you feel it all the way down a little bit further you'll feel this big bump on
00:02:3700:02:43
the tibia right, so patella, patella ligament I guess if you want to call it
00:02:4300:02:49
that, and then tibial tuberosity here is the big bump. Once you find that big bump
00:02:4900:02:52
you know you're on the tibia, and then we're going to kind of move laterally
00:02:5200:03:00
here, and you'll notice that as you move laterally there is kind of another bump
00:03:0000:03:06
which actually belongs to your fibula, it's a different bone. If you feel a
00:03:0600:03:11
little bit you can actually feel how the the tibia goes into the tibial plateau
00:03:1100:03:16
here, alright so if I come up like this I can kind of feel how it divots out and
00:03:1600:03:21
then the fibular head kind of connects right up into that, and I'm going to go
00:03:2100:03:27
ahead and use my thumb's to just trace that fibula out, I want to feel all the
00:03:2700:03:34
way around the fibular head; and remember guys you can do this with a patient or
00:03:3400:03:39
client, you don't have to just boom there's the fibular head, like you don't
00:03:3900:03:44
have to 100% accuracy on finding these these points every time. Remember your
00:03:4400:03:48
patient or client does not know how long it's supposed to take you to find
00:03:4800:03:54
something, you're better off being a little slower and right than trying to
00:03:5400:03:59
place your hands down and being wrong. So now that I've found the fibular head and
00:03:5900:04:06
I found the tibia, what I need to do is does this joint move and guys you need
00:04:0600:04:13
to be careful, because you have the peroneal nerves as well as a very tender
00:04:1300:04:18
soleus trigger point or common trigger point site right behind the fibular head.
00:04:1800:04:25
So as you guys go to push on this just use as broad a thumb stroke as you can.
00:04:2500:04:32
Right so I have all this tibia right here, I have my fibular head, I'm going to
00:04:3200:04:36
use this hand, I'm going to put this one down right between where I think the
00:04:3600:04:40
tibia and fibula head is, kind of where I think the joint line is, and then I'm
00:04:4000:04:45
going to go ahead and see does my fibula wiggle. Just like we were talking about
00:04:4500:04:52
with the distal tibiofibular joint, this joint doesn't move a lot, and if it does,
00:04:5200:04:59
and it does move easily you're hyper- mobile. Hypermobile no mobilization. If
00:04:5900:05:05
it doesn't move at all, or barely moves like you have to press pretty hard to
00:05:0500:05:10
get it to move what even feels like one millimeter, then this is probably a joint
00:05:1000:05:17
that you want to go ahead and mobilize. Now I don't feel a whole lot of motion, I
00:05:1700:05:22
do see some scrunching of the face so I need to be careful. Guys in most
00:05:2200:05:25
situations for this particular joint you're probably going to have to go
00:05:2500:05:31
ahead and do your your soleus release first, do some soft tissue release around
00:05:3100:05:34
the fibular head, because if you don't everytime you go to push on that joint
00:05:3400:05:38
you're just going to keep digging into that trigger point, you're going to watch
00:05:3800:05:41
your your clients face scrunch, and then they're going to guard and you're not
00:05:4100:05:46
going to get a whole lot of motion anyway. To do this technique with a
00:05:4600:05:52
little bit better hand position, I would suggest either trying to put the fibular
00:05:5200:05:55
head here in your thumb and kind of wrap around so that you have all this broad
00:05:5500:06:04
surface, or you could even try thenar eminence, hand over hand like
00:06:0400:06:11
this. Whichever way you do it, this like just using the point of your thumb is
00:06:1100:06:16
not going to work really well. Anytime I've tried to get that to work I get a
00:06:1600:06:22
lot of like a lot of guarding, it's just very painful it's very pokey. So I'm
00:06:2200:06:26
going to go ahead and try to wrap my, oh maybe not, I'm going to use my thenar
00:06:2600:06:30
eminence here, my thumb's are a little big to get to get around that fibular
00:06:3000:06:34
head. Once I found that that thenar eminence, notice guys my arms are nice
00:06:3400:06:40
and straight, and I'm just going to go ahead and push in a posterior to
00:06:4000:06:46
anterior direction. Now we talked about how my Maitland
00:06:4600:06:50
certified orthopedic manual therapist, so that's the protocol I know, I'm going to
00:06:5000:06:56
find that first resistance barrier, I'm going to find the arthrokinematic end
00:06:5600:06:59
range, assuming this is a stiffness dominant patient we're not looking at
00:06:5900:07:05
pain dominant, and then I'm going to back off to 50% and then that can either do
00:07:0500:07:11
my grade three mobilizations from first resistance barrier to around 50%, little
00:07:1100:07:18
larger amplitude, or I can go right up to 50% and use small amplitude right at
00:07:1800:07:24
that increased resistance, and see if I can get more movement there; and of
00:07:2400:07:29
course I'm going to do one to two oscillations per second until I feel a
00:07:2900:07:35
change in joint mobility. Now this is somewhat a challenging technique and
00:07:3500:07:39
sometimes you guys are going to have to mess with with foot placement, because
00:07:3900:07:45
what your clients going to want to do is either you can see kind of roll at the
00:07:4500:07:52
hips, or you go to push and they they they start moving here. So it's going to
00:07:5200:08:00
take a little bit of experimentation sometimes to get them into a position
00:08:0000:08:10
where you can use this technique, and get motion at the joint without just rocking
00:08:1000:08:15
their whole body. Remember all we're looking for is a little tiny bit of
00:08:1500:08:21
motion here, not thisl if you find you're doing one of these things to move the
00:08:2100:08:26
joint -I guarantee you've pests pressed well past arthrokinematic end range and
00:08:2600:08:30
now you're rocking their entire body, and that's probably not that effective of
00:08:3000:08:36
a technique. So let's kind of go through this again. Our contraindications
00:08:3600:08:40
are the peroneal nerve, and then we need to be aware of that soleus trigger point
00:08:4000:08:45
that's going to be real tender. We want to use a nice broad surface so
00:08:4500:08:50
either put the fibular head in the IP of your thumb and then wrap your
00:08:5000:08:53
thumb around it, or if you're like me and you can't quite get your thumb in there,
00:08:5300:09:00
maybe you want to use your thenar eminence. Experiment with position of the the knee,
00:09:0000:09:05
foot behind one foot, you can set up bolsters if you need to if you think
00:09:0500:09:11
that'll help. You can change the angle of their hips, but get into a position where
00:09:1100:09:15
you feel like when you push here you're getting motion of the fibular head on
00:09:1500:09:20
the tibia and not just motion of the whole body. I might even be able to brace
00:09:2000:09:30
her thigh a little bit and use one hand, so I suppose you could do that, but again
00:09:3000:09:36
thenar eminence, I'm pushing posterior to anterior, first resistance barrier now,
00:09:3600:09:43
end range is right about there, I'm going to back off the 50% and then I'm going
00:09:4300:09:46
to start with the grade three immobilization here, back off to nothing
00:09:4600:09:52
and go up to 50%, one to two oscillations per second, checking on my client making
00:09:5200:09:59
sure she isn't cringing because I'm on top of her peroneal nerve, or I'm on top
00:09:5900:10:06
of that soleus trigger point; and then I'm looking for a change in the amount
00:10:0600:10:13
of stiffness of this joint, and then as I explained in the distal tibiofibular
00:10:1300:10:18
joint mobilization it is a little hard to feel change with your thenar eminence,
00:10:1800:10:23
so I'm probably going to go back in and do my little test of how much wiggle I
00:10:2300:10:27
got with my fingertips here, and I got a little bit more wiggle.
00:10:2700:10:32
So whatever her test was after that that provoked her pain, I might have her do
00:10:3200:10:34
maybe she was having knee pain during a squat. to be like alright let's get up
00:10:3400:10:38
and squat and see how that felt. Of course if there was no change
00:10:3800:10:42
onto the next technique, if there was change it definitely want to make
00:10:4200:10:46
note, well either way I want to make note so that I keep doing that in successive
00:10:4600:10:50
sessions, to make sure that we're building the most effective program that
00:10:5000:10:55
we can. Stay tuned for the close of recap. The close-up recap of our proximal tibia
00:10:5500:11:00
fibula joint mobilization, thats a posterior to anterior mobilization of the fibula
00:11:0000:11:04
head. You guys can see here I actually have my thumb right on the fibular head
00:11:0400:11:08
but if you've never palpated the fibular head before, my suggestion is actually to
00:11:0800:11:13
start with something you you know how to palpate like the the patella right, you
00:11:1300:11:17
all know where your kneecap is, and then you can kind of follow the the patella
00:11:1700:11:22
ligament or patellar tendon down to the tibial tuberosity, that's that big bump
00:11:2200:11:26
right here where the patellar tendon attaches, and then if you go lateral from
00:11:2600:11:32
that you run into this bony prominence that if you feel around a little bit is
00:11:3200:11:40
kind of half spherical shape, that is your fibular head. Now what you're going
00:11:4000:11:46
to want to do is kind of palpate and explore so that you can get behind that
00:11:4600:11:53
joint that fibular head, and then kind of find in front of it so that your fingers
00:11:5300:11:57
are around it, and now you need to see if maybe you can wiggle that fibular head,
00:11:5700:12:04
alright so we're checking out how much motion do we have at the proximal tibiio-
00:12:0400:12:08
fibula joint, essentially doing a passive accessory
00:12:0800:12:13
motion assessment of some sort. Again this is this is one of those joints that
00:12:1300:12:16
just wiggles a little bit, if it Wwiggles a lot you're probably
00:12:1600:12:22
hypermobile and don't need this, if it wiggles really easy then maybe it's fine
00:12:2200:12:28
as long as it doesn't wiggle too much. If it seems really stiff and it seems like
00:12:2800:12:32
you have to apply quite a bit of pressure, that's where we're thinking okay
00:12:3200:12:37
maybe I need to mobilize this joint, maybe mobilizing this joint will help the
00:12:3700:12:42
knee move better or the ankle move better, or help reduce the tenacity in
00:12:4200:12:48
things like the TFL, vastus lateralis and biceps femoris which invest in the
00:12:4800:12:54
fibular head here. Things to keep in mind is there is a trigger point right behind
00:12:5400:12:59
the fibular head it's a soleus trigger point, so if you just keep pressing down on that
00:12:5900:13:03
you're doing your oscillatory mobilizations, you're not going to make
00:13:0300:13:06
your client or patient very happy. It might be a good idea to do some soft
00:13:0600:13:11
tissue work in the in the posterior lower leg here before before you do this
00:13:1100:13:14
technique. The other thing you have to be concerned with is the
00:13:1400:13:18
peroneal nerve which if you pinch on, your your client a patient's going to
00:13:1800:13:21
let you know; and of course nerves are pretty thin, so you should just be able
00:13:2100:13:27
to move your your hands around a little bit and get away from that nerve. You
00:13:2700:13:30
don't want to use thumbs like this because that's going to feel really
00:13:3000:13:34
really pokey, what you're going to need to do to do this mobilization is use
00:13:3400:13:40
either your thenar eminence, or as much of your thumb pad as you can. For people
00:13:4000:13:44
with a little smaller hands than mine I usually suggest them trying to put the
00:13:4400:13:49
fibular head kind of in their IP joint like so, and then you can actually kind
00:13:4900:13:54
of use this as a dummy thumb and put the other hand over it right, now your other
00:13:5400:14:00
hand is in the right direction to do a posterior to anterior mobilization. So in
00:14:0000:14:06
Melissa's case I did my little wiggle, she doesn't wiggle much, I'm going to put
00:14:0600:14:12
this dummy thumb like this, put my thenar eminence over like this, I'm going to
00:14:1200:14:17
find my first resistance barrier right there, the end of our arthrokinematic
00:14:1700:14:22
range which was right there, let me go at that a little bit slower so I can find
00:14:2200:14:29
50%, and then I can go from zero to 50% do my grade three mobilizations here,
00:14:2900:14:38
until I feel what I think is a reduction in joint stiffness; and then of course I
00:14:3800:14:43
could reassess. Now I did mention that it is a little bit of a challenge in this
00:14:4300:14:49
position to get pure fibular head motion on tibia and not just get somebody
00:14:4900:14:53
rocking back and forth, so don't be afraid to like hook one foot behind the
00:14:5300:14:56
other, bend the knee a little bit more, bend the
00:14:5600:15:00
knee a little bit less. Use bolsters change the position of their hip,
00:15:0000:15:06
whatever you have to do to try to get into a good position so that you can
00:15:0600:15:13
kind of block them out, and get some good fibular head motion. So there you have it
00:15:1300:15:18
assess, address, reassess. Make sure that every time you choose a joint based
00:15:1800:15:23
manual therapy technique it is based on an assessment, and that you return to
00:15:2300:15:25
that assessment after you've finished the intervention
00:15:2500:15:30
to see if it was effective for the individual, the patient or client that
00:15:3000:15:34
you have in front of you. Ensure that you continue to learn your Anatomy because
00:15:3400:15:39
your Anatomy is going to help you with your hand placement, with understanding
00:15:3900:15:45
what a joint can do, with understanding what you may gain from this particular
00:15:4500:15:50
technique; and of course practice you have to practice these techniques,
00:15:5000:15:55
hopefully not for the first time on a patient or client who just walked in the
00:15:5500:16:00
door. If you can find a more senior instructor or mentor to give you some
00:16:0000:16:07
really good hands-on instruction, use your peers for some good feedback, and of
00:16:0700:16:14
course always look for live education to help with your manual therapy techniques.
00:16:1400:16:19
I know these videos make education very convenient, but there is no substitute
00:16:1900:16:24
for learning manual therapy in a live setting, I look forward to talking to you
