Shoulder Extension Goniometry

Shoulder Extension Goniometry is an assessment tool used to measure the range of motion of the shoulder joint. It is commonly used by physical therapists and doctors when screening patients with shoulder injuries or to evaluate progress of rehabilitation from shoulder surgery. The measurements obtained from shoulder extension goniometry are valuable in diagnosing shoulder joint pathology, assessing shoulder joint function, and creating individualized treatment plans for shoulder injuries.

Transcript

00:00:0600:00:09
This is Brent of the Brookbush Institute at the
00:00:0600:00:09
independent training spot. Today we're
00:00:0900:00:13
doing shoulder extension goniometry. now for shoulder extension we have a
00:00:1300:00:17
firm end feel, it's like pulling leather to its end range you get a lot of
00:00:1700:00:22
resistance, and then a pretty firm stop, and you guys will notice that I have 20
00:00:2200:00:27
to 25 degrees of shoulder extension written down as being optimal. Now if you
00:00:2700:00:31
open up a textbook often shoulder extension goniometry is listed at 60
00:00:3100:00:38
degrees. The reason being is that includes free motion of the shoulder
00:00:3800:00:43
girdle, that is it allows anterior tipping to occur as much as it can, plus
00:00:4300:00:49
glenohumeral extension. Now from what I've seen guys and you might work in a
00:00:4900:00:52
different clinic with a different audience, and and that makes perfect
00:00:5200:00:56
sense for what you're working on, what I see is a lot of this when people walk in.
00:00:5600:01:01
They already have an excessive amount of anterior tipping, so if i'm going to do
00:01:0100:01:05
shoulder extension I don't want to include a range they might be hyper
00:01:0500:01:09
mobile in. Alright so they might be stealing range of motion from their scapula and
00:01:0900:01:14
still be restricted at the shoulder, and I wouldn't know. So I do pure
00:01:1400:01:20
glenohumeral shoulder extension, which is why you see such conservative numbers.
00:01:2000:01:23
I'm going to have my friend Melissa come up she's going to help me demonstrate this
00:01:2300:01:30
technique. Alright so the the different thing about this technique from some of
00:01:3000:01:35
our other shoulder goniometry techniques is we have to not only
00:01:3500:01:40
depress the scapula, but now we have to stabilize the scapula and keep it from
00:01:4000:01:44
once again going into anterior tipping. So I'm gonna use my inner thenar
00:01:4400:01:49
eminence here right, the space right here to press down on her inferior angle and
00:01:4900:01:55
basically posterior tip it, flatten it down to her rib cage. I'm then going to
00:01:5500:01:59
go ahead and pull her into shoulder extension but I'm not going to do it by
00:01:5900:02:04
her wrist. If I do it by her wrist I'm going to heavily bias this test towards one
00:02:0400:02:09
her biceps brachii, and two potentially some nerves right. This kind of looks
00:02:0900:02:13
looks like the beginning of that radial and median nerve test if I were to flip
00:02:1300:02:17
her over. So because I want to see everything that's kind of going on at
00:02:1700:02:21
the shoulder, I want to see how her glenohumeral joint specifically is
00:02:2100:02:25
affected, I'm going to go ahead and take two fingers lift her up at the elbow,
00:02:2500:02:29
allow her to go into some elbow flexion so that at least those structures that
00:02:2900:02:33
we just talked about the biceps brachii and some of the nerves of your arm, have
00:02:3300:02:38
a little bit more room to move and I get a little bit more general sense of what
00:02:3800:02:44
is blocking shoulder extension. So we're going to brace, press down into the
00:02:4400:02:49
ribcage, and then pull her up by your elbow. I'm going to flip around here and
00:02:4900:02:52
show you guys what this looks like.
00:02:5400:02:58
Alright so I'm going to use this hand and hand closer to my patient, depress her
00:02:5800:03:03
scapula, and then go ahead and push her into posterior tipping, basically
00:03:0300:03:09
flattening her scapula into her rib cage. I'm then going to use this hand to pull
00:03:0900:03:13
her into shoulder extension from the elbow, making sure I cue her to relax. This
00:03:1300:03:18
is one of those those ranges of motion that people like to help you, and we want
00:03:1800:03:21
to make sure we get passive range of motion here. I actually like to use my
00:03:2100:03:27
thigh right up against the table to make sure they don't go into abduction. I can
00:03:2700:03:30
kind of keep around the sagittal plane here making sure she doesn't try to
00:03:3000:03:35
internally rotate and abduct, she doesn't externally rotate on me, I get nice pure
00:03:3500:03:39
shoulder extension. Once I get her there, I'm going to have her hold, can you hold
00:03:3900:03:45
that for me good. We're then going to line up our pivot point here with the
00:03:4500:03:52
center of the the shoulder joint, as close as we can estimate. The movement
00:03:5200:03:54
arm goes through this orange line that I've taped for you guys here which is
00:03:5400:04:01
just the midline, the lateral midline of the humerus to lateral condyle, and then
00:04:0100:04:08
the stabilization arm is mid-axillary line perpendicular to the table, make
00:04:0800:04:13
sure I'm eye level with my measurement and I get 22 degrees.
00:04:1300:04:17
So I'll show you guys that a little bit faster this time just like I would run
00:04:1700:04:24
through it in my own practice. We're going to push down, stabilize, pull up, oh
00:04:2400:04:32
don't help me, good can you hold that, cool all right
00:04:3400:04:41
and that time I got 20 degrees. That's within 2 degrees, either way she has
00:04:4100:04:46
normal range of motion right, she's she's within that 20 to 25 degrees. Thank you
00:04:4600:04:50
Melissa. So let's talk about what it would mean if like let's say I did this
00:04:5000:04:55
measurement and Melissa had 12 degrees of shoulder extension, well that means I
00:04:5500:05:01
have some sort of restriction right. This goniometry in general helps us
00:05:0100:05:06
identify structures that could be restricted that we could then create
00:05:0600:05:09
interventions for. I'm going to take you guys through the same paradigm that I've
00:05:0900:05:12
taken you through in all the other videos, we're going to do muscle, joint
00:05:1200:05:18
fascia, nerve. Let's start with muscles, we got PEC major think about how many
00:05:1800:05:24
individuals come in with a short and overactive PEC major right, this position.
00:05:2400:05:28
Anterior deltoid, this is one of the few tests that we have that actually
00:05:2800:05:33
implicates this structure which is kind of interesting, you know can somebody
00:05:3300:05:37
have shortness and tightness in that anterior deltoid that maybe needs to be
00:05:3700:05:41
treated out, so that we get optimal movement back and a reduction in symptoms.
00:05:4100:05:47
The coracobrachialis another interesting muscle that isn't implicated many of our
00:05:4700:05:52
other tests, our coracobrachialis is is one of those hidden structures that's
00:05:5200:05:56
often forgotten, it may be worth checking out if you have somebody who's had a
00:05:5600:06:00
little bit of stubborn shoulder pain, or they had that upper body dysfunction
00:06:0000:06:06
that that you having a hard time relieving them of. Before I get to post
00:06:0600:06:12
deltoid let's talk about joint real quick. So joint we have the anterior capsule
00:06:1200:06:18
could be restricting, we have the coraco- humeral ligament which is probably
00:06:1800:06:23
actually why we get a firm end feel on this particular range of motion. If we
00:06:2300:06:29
probably hit a hard end to this ligaments extensibility. And then we get
00:06:2900:06:34
down here guys and you'll see two structures that I have starred, and
00:06:3400:06:38
that's the posterior capsule and posterior deltoid, and if you're thinking
00:06:3800:06:42
through this like I am you guys are already going wait a second if I go on
00:06:4200:06:46
to shoulder extension I'm shortening these two things,
00:06:4600:06:52
why does he have listed as possible restrictions. Well the truth of the
00:06:5200:06:58
matter is is what can happen for this range of motion, is often the humerus the
00:06:5800:07:03
humeral head will shift anteriorly in the glenoid fossa all right, we have an
00:07:0300:07:08
anterior migration of that humeral head which means the anterior capsule is
00:07:0800:07:14
actually not short in that scenario it's been lengthened, but because it's already
00:07:1400:07:19
been lengthened by for word translation, when you pull into extension you hit the
00:07:1900:07:24
end of the anterior capsules extensibility. The reason that's
00:07:2400:07:30
occurring is because we actually have posterior deltoid overactivity, an adaptive
00:07:3000:07:35
shortening of the posterior capsule basically squeezing the humeral head
00:07:3500:07:41
forward. So if you're looking at some of these structures, you've been working
00:07:4100:07:44
with some of these structures with whatever techniques you're comfortable
00:07:4400:07:50
with you're not getting your results, check this out. Sometimes all you have to
00:07:5000:07:55
do is is that self-administered posterior deltoid release, maybe a little
00:07:5500:08:00
bit of a sleeper stretch, and shoulder extension miraculously goes back to
00:08:0000:08:08
optimal. Now fascia for all of all of you guys using ART and our
00:08:0800:08:13
instrument assisted soft tissue mobilization, and pin and stretch and all
00:08:1300:08:17
of the different fascial techniques that are out there, don't forget about all of
00:08:1700:08:23
the covering fascia in this area right. You have all of this stuff, all of this
00:08:2300:08:29
stuff all that fascia that comes down into that that pectoral deltoid triangle,
00:08:2900:08:35
right all of this anterior deltoid fascia that tends to get restricted. You know if
00:08:3500:08:38
we're going to come up with an example and all of my individuals who do this
00:08:3800:08:46
all day, all right we might want to loosen or start unbinding all of that
00:08:4600:08:50
tissue in there. And then of course guys if I had pulled Melissa up into shoulder
00:08:5000:08:55
extension she started getting tingly and numb, tingling, numbness parasthesia,
00:08:5500:09:02
pins and needles, I need to go ahead and break out into those upper limb
00:09:0200:09:07
tension tests. I need to see if maybe my brachial plexus is involved in some of
00:09:0700:09:13
this limitation, or some of the nerves of the arm. So once again big list, some
00:09:1300:09:18
complicated arthrokinematics here, but nonetheless you know how I like you
00:09:1800:09:21
guys to think of this. This isn't something for you guys to panic about,
00:09:2100:09:26
it's not something for you guys to be overwhelmed by, I want you to look at
00:09:2600:09:32
this chart and go I have a lot of opportunities and potential solutions to
00:09:3200:09:37
help correct a movement impairment, in this particular video shoulder extension.
00:09:3700:09:41
I hope to hear about great outcomes thank you.
