Shoulder Flexion Goniometry
Shoulder flexion goniometry is a medical evaluation technique used to measure the range of motion in a person's shoulder joint. This measurement is taken through a series of joint motions. During the procedure, an examiner moves the patient's shoulder in multiple directions, such as forward flexion, abduction, and internal and external rotation. With the aid of a goniometer, the range of motion in each direction is recorded, providing a detailed assessment of the shoulder joint and its motion capabilities.
Transcript
00:00:0600:00:09
This is Brent of the Brookbush Institute at
00:00:0600:00:09
the independent training spot in New
00:00:0900:00:12
York City, and we're going over more goniometric assessment. In this video
00:00:1200:00:16
we're going to do shoulder flexion, a range of motion that everybody should be
00:00:1600:00:20
very familiar with because of its correlation to function. Now we're going
00:00:2000:00:24
to go over both glenohumeral flexion, as well as shoulder complex flexion.i'm going to
00:00:2400:00:27
have my friend Melissa come out, she's going to help me demonstrate these
00:00:2700:00:30
techniques.
00:00:3000:00:33
Now notice I said glenohumeral and shoulder complex and I separated those
00:00:3300:00:37
numbers, I think some of the confusion and range of motion of the shoulder
00:00:3700:00:42
actually has to do with this particular technique. If you stabilize the scapula
00:00:4200:00:46
and you're testing just just the shoulder itself just the glenohumeral
00:00:4600:00:51
joint, you should be looking for about a hundred and twenty degrees. Now if we
00:00:5100:00:56
allow the scapula to move freely the entire shoulder complex, SC joint, AC
00:00:5600:01:00
joint and the glenohumeral joint, we should be looking at about a hundred and
00:01:0000:01:06
eighty degrees. Now regardless of which technique I'm doing I generally set up
00:01:0600:01:10
the same way, and to make sure her her arms nice and straight, and I start with
00:01:1000:01:15
her scapula depressor I know she's starting in a good position, and then i'm going to
00:01:1500:01:21
use this little groove between my thenar my hypothenar eminence,
00:01:2100:01:28
over the top of her little inferior angle of her scapula. Or I can use
00:01:2800:01:34
just my thumb, problem with just your thumb although it's easier on the
00:01:3400:01:38
physical therapist, sometimes it's harder on the patient because it's a little
00:01:3800:01:43
more pokey, but if I'm doing just glenohumeral right, I'm going to only
00:01:4300:01:47
take her shoulder up until I start to feel her scapula go up into upward
00:01:4700:01:52
rotation. I'm gonna try to brace it, make sure i get to my hard end feel, and then
00:01:5200:01:57
i'm going to take the measurement. Now if i'm looking for just general shoulder
00:01:5700:02:03
complex range of motion then i might keep my hand there just at a habits sake,
00:02:0300:02:08
but i'm going to go ahead and let her move and pull her straight into flexion.
00:02:0800:02:14
Now of course I'm only reaching across her so you guys can see on camera, if I
00:02:1400:02:18
was going to do this technique from my own personal measurements on one of my
00:02:1800:02:22
patients or clients, I'm going to have her scoot towards me as far as she can, and
00:02:2200:02:26
i'll usually use my leg and say you know scoot all the way to my leg. Her scapula
00:02:2600:02:30
should be on the table, her shoulder should be off the table right. I'm going to
00:02:3000:02:35
go ahead and feel for her scapula there and i guess i use the thumb a little bit
00:02:3500:02:40
more, once i get her to
00:02:4000:02:47
end range which is right there, I'm going to say hold that. Alright she's going to hold that
00:02:4700:02:54
for me. I'm going to go ahead and take my goniometer here and the stabilization
00:02:5400:02:58
arm is a mid-axillary line right, so you guys can think straight through the
00:02:5800:03:02
armpit down to the top of the iliac crest, that line would continue straight
00:03:0200:03:07
through the greater trochanter. My fulcrum is going to be as close to me
00:03:0700:03:14
estimating the middle of the glenohumeral joint, and then the movement
00:03:1400:03:18
arm goes straight through mid line in her arm, and she has a hundred and
00:03:1800:03:24
fifteen degrees of glenohumeral flexion. Now i'm going to show you guys because
00:03:2400:03:30
in both the instances i just showed you, both reaching across and this way being
00:03:3000:03:33
blocked by the board, I didn't show you guys great technique, but I'm going to
00:03:3300:03:37
have to turn my back on you to go through this properly. So
00:03:3700:03:41
once again I'm going to have her scoot all the way towards me, I'm going to block out with
00:03:4100:03:45
my leg here, make sure she doesn't slide right off the table. So her shoulders off,
00:03:4500:03:52
but her scapula's on. If i'm doing glenohumeral I'm going to use my thumb here
00:03:5200:03:59
alright, I'm going to pull her back just when I feel that end range. I'm going to
00:03:5900:04:04
have her hold. Now as i mentioned in other videos i want to get in eye line
00:04:0400:04:09
right with her shoulder now, my movement arm is going to go straight through the
00:04:0900:04:16
midline of her humerus, fulcrums going to line up through mid glenohumeral joint here, and
00:04:1600:04:20
then the mid-axillary line goes straight through the middle of the armpit to the
00:04:2000:04:28
top of the iliac crest, straight through the greater trochanter, and hold,, and I
00:04:2800:04:34
got 115 degrees. Now a nice general measurement like i said if i was doing
00:04:3400:04:42
shoulder complex right, 180 degrees would be a straight line. So i'd start her off,
00:04:4200:04:47
all right can she in straight plane go all the way back to the table, if she
00:04:4700:04:50
could we already know she has 180 degrees I don't even have to pull out
00:04:5000:04:55
the goniometer. If she had gotten stuck let's say here, hold that for me, I
00:04:5500:05:02
would just go back through the same technique. A line midway through the
00:05:0200:05:09
humerus, mid-axillary line and if she only had that much flexion that would be
00:05:0900:05:15
roughly a hundred and forty-five degrees. So hopefully you guys can now see how
00:05:1500:05:24
this technique is lined up. Thank you Melissa. Alright so we just did flexion
00:05:2400:05:28
goniometry, we got a hundred and forty-five made-up degrees restriction,
00:05:2800:05:33
now what do we do right, if we're going to do a test it better either clear us
00:05:3300:05:38
as like a lot of our diagnostic tests do, or better have an impact on exercise
00:05:3800:05:41
selection, otherwise why are we doing the test. If we're doing goniometry we're
00:05:4100:05:45
looking at restrictions, if she's only 145 degrees I know she's restricted
00:05:4500:05:51
in flexion. How am I going to get her to move better, well I have to start
00:05:5100:05:54
thinking about the things that could restrict flexion. Let's start with
00:05:5400:05:59
muscles. So we got some really big muscles right the lats, the teres major,
00:05:5900:06:08
part of the PEC major will all restrict shoulder flexion, the subscapularis right
00:06:0800:06:11
even though it's just it's an it's listed as an internal rotator in most of
00:06:1100:06:17
your textbooks, it will also restrict flexion. The posterior deltoids right as
00:06:1700:06:22
we especially get up into this in range can restrict flexion, it can also have a
00:06:2200:06:29
a big effect on arthorkinematics and not glide the humeral head posteriorly
00:06:2900:06:36
as we go into flexion. And then if we were only doing glenohumeral flexion
00:06:3600:06:43
that's would be where this list stopped. But if you did shoulder complex flexion
00:06:4300:06:48
right now night now you just don't have shoulder flexion, you have shoulder
00:06:4800:06:55
flexion with potentially upward rotation, and posterior tipping alright. So I
00:06:5500:07:00
listed the posterior are the anterior tippers here those things with that
00:07:0000:07:03
would restrict posterior tipping, which would be the PEC minor and levator
00:07:0300:07:11
scapulae. So if I know these muscles can restrict this motion I may start
00:07:1100:07:16
attacking these with release techniques, lengthening techniques, pin and stretch
00:07:1600:07:22
techniques right. I have put stars by subscapularis, post delt and PEC minor. I
00:07:2200:07:26
know those of you who've been in the clinic for a while and done a lot of manual
00:07:2600:07:32
therapy, these three for manual release work like magic to improve shoulder
00:07:3200:07:37
flexion, so that might be a note you want to take. Joints alright so let's talk
00:07:3700:07:42
about the glenohumeral joint here we have posterior capsule, posterior cord of
00:07:4200:07:47
the coracle humeral ligament, and the inferior capsule which could all
00:07:4700:07:53
restrict flexion. So now what am I going to do, well we start thinking towards our
00:07:5300:07:57
mobilization techniques, things like our anterior to posterior glide, may be
00:07:5700:08:02
inferior glides, may be more general lateral distractions to work
00:08:0200:08:12
that posterior capsule, and don't forget AC and SC joints here, you really have to
00:08:1200:08:16
start thinking beyond just the shoulder if you're working in shoulder flexion,
00:08:1600:08:20
realizing that if we're looking at that hundred and eighty degrees of shoulder
00:08:2000:08:26
complex flexion, the scapula is also involved. Inferior SC joint mobilizations,
00:08:2600:08:34
posterior to anterior AC joint mobilizations work wonderfully. Fascia
00:08:3400:08:43
your clavi-pectoral, pectoral fascia and axillary fascia, all could use maybe a
00:08:4300:08:48
little instrument assisted soft tissue mobilization, all could definitely use a
00:08:4800:08:56
little attention from our myofascial bag of tricks to help relieve some of
00:08:5600:09:04
this restriction, and then of course if somebody got some nerves stuff, we would
00:09:0400:09:07
want to go ahead and do neurodynamic test. Unfortunately this is such a
00:09:0700:09:13
general stretch to the brachial plexus which goes down through our scalenes, and
00:09:1300:09:16
then underneath or clavicle, between our clavicle and our first rib and then
00:09:1600:09:20
underneath our pectoralis minor than just doing this, there's so many places to
00:09:2000:09:27
become restricted this would be a bad test for any one nerve, but maybe a sign
00:09:2700:09:32
that we need to go ahead and test further. Now a personal thought on this
00:09:3200:09:38
test, this is one of those goniometric assessments that i'll use if i have to
00:09:3800:09:43
because somebody else told me I had to, and what I mean is if somebody else is
00:09:4300:09:48
relying on flexion as a number to get back to playing sports, or a surgeon is
00:09:4800:09:54
looking for this number, or if somebody came in and this was the range of motion
00:09:5400:09:59
they felt most limited in, of course I'll use this test. What you guys will notice
00:09:5900:10:05
from this graph though is it's not starkly different from external rotation.
00:10:0500:10:10
So because I don't get all that much additional information from this test, if
00:10:1000:10:14
I've already done external rotation, which for me it's real easy to do
00:10:1400:10:19
internal rotation and external rotation and write those numbers down, for
00:10:1900:10:24
me i'll use external rotation instead of this test sense from a practical
00:10:2400:10:31
application standpoint, I tend to get the same information. So with all of the
00:10:3100:10:34
videos guys I hope this isn't intimidating, that it gives you a ton of
00:10:3400:10:39
ideas. I hope you will use this technique immediately if not on your colleagues
00:10:3900:10:42
then your friends, and then your colleagues, then of course you'll start
00:10:4200:10:46
using on patients because unless you practice it you're not going to remember
00:10:4600:10:51
it, you're not going to use it, and you won't take advantage of all of this
00:10:5100:10:55
potential information that comes with it. I look forward to hearing from you guys
00:10:5500:10:57
soon.
Related Videos
Femoral Nerve Neurodynamic Tests
Lumbar Movement Assessment
Slump Test
Upper Body Movement Assessment
Straight Leg Raise Test and Well Leg Raise Test
Hip Flexion Goniometry
Hip Extension Goniometry
Goniometry Hip Internal Rotation (in prone)
Knee Extension with Hip Flexion Goniometry (Hamstring Length Test)
Goniometry: Hip External Rotation at 90 Degrees of Hip Flexion (90/90 Hip ER)
Goniometry: Hip Internal Rotation at 90 Degree of Hip Flexion (90/90 Hip IR)
Ober's Test TFL Flexibility Assessment
Shoulder External Rotation Goniometry
Ely's Test (Rectus Femoris Flexibility Assessment)
Goniometry Hip External Rotation (in Prone)
